IS215VCMIH2C被設計為GE Mark VI渦輪控制系統中的VME通信卡，對整個系統的正確功能至關重要。VCMI VME通信板支持I/O卡與安裝在VME背板上的其他I/O卡、安裝在擴展機架上的I/O卡、I/O備份保護模塊、三冗余控制模塊、主處理器模塊或主處理器模塊之間的通信。
IS215VCMIH2C卡也被廣泛地稱為VME總線主控制器。該PCB板為I/O板和控制器之間的通信提供接口。它還充當系統控制網絡(IONet)的通信接口。
IS215VCMIH2C
IS215VCMIH2C在其前面板上有四個端口連接。這些包括一個RS-232C串口、d型插頭連接器和三個IONet 10Base2以太網端口。每個IONet連接器都與三個標有TX/RX/CD的LED指示燈相關聯。單板有額外的LED指示燈(Status、Fail、Run、1、2、4、8)。前者位于復位開關(按鈕)的上方，而后者位于串口的正下方。
Mark VI系統中的每個控制模塊通常包含一個IS215VCMIH2C，這些獨特的VCMI卡通過控制系統的應用軟件與主處理器模塊通信執行數據。由于VCMI模塊的關鍵性質，建議在架子上保留額外的備件，以避免機器停機的情況。
IS215VCMIH2C
The IS215VCMIH2C is designed as a VME communication card in the GE Mark VI turbine control system and is essential for the proper functioning of the entire system. VCMI The VME communication board supports the communication between the I/O card and other I/O cards installed on the VME backplane, I/O cards installed on the expansion rack, I/O backup protection module, triple-redundancy control module, main processor module, or main processor module.
The IS215VCMIH2C card is also widely known as the VME bus master controller. The PCB provides an interface for communication between the I/O board and the controller. It also acts as a communication interface for the System Control Network (IONet).
The IS215VCMIH2C has four ports connected on its front panel. These include an RS-232C serial port, type d plug connectors, and three IONet 10Base2 Ethernet ports. Each IONet connector is associated with three LED indicators labeled TX/RX/CD. The board has additional LED indicators (Status, Fail, Run, 1, 2, 4, 8). The former is located above the reset switch (button), while the latter is located directly below the serial port.
Each control module in the Mark VI system typically contains an IS215VCMIH2C, and these unique VCMI cards communicate with the main processor module to execute data through the control system’s application software. Due to the critical nature of the VCMI module, it is recommended to keep additional spare parts on the shelf to avoid the situation of machine downtime.
IS215VCMIH2C
