IS215VPROH1B是為Mark VI系統制造的模塊。Mark VI是來自Speedtronic生產線的燃氣/蒸汽輪機管理系統，GE已經開發了30多年，專注于創建可靠和高效的系統。

IS215VPROH1B作為應急渦輪保護模塊。IS215VPROH1B提供速度差檢測和備份同步檢查保護。該板接受熱電偶和模擬輸入。這個模塊有兩個電路板堆疊在一起。頂部板是一個IS200VPRW板，通過四個螺紋連接安裝到底部板上。電路板由集成電路、變壓器、幾個晶體管以及電阻、電容器和二極管組成。電容器包括聚酯乙烯基制成的電容器。電阻器有時由碳復合材料制成。電路板有幾個電感線圈和許多連接器，包括插頭。有一個散熱器位于右前方。

IS215VPROH1BD

IS215VPROH1B的底板有兩個背板。它有電容器、電阻和多個集成電路。這包括振蕩芯片。頂板的邊角放置在板子的邊緣附近。

IS215VPROH1B通過TREG板控制跳閘螺線管?？刂破鲀?nèi)的應用軟件用于啟動這些行程螺線管的測試。這些也可以手動觸發。

IS215VPROH1B采用面板制造。面板有LED指示器，電源開關，電纜連接器和以太網連接器。這個面板用螺絲連接到電路板上。有關該模塊的更多信息可以使用原始設備制造商的出版物找到。

IS215VPROH1BD

IS215VPROH1B is a module manufactured for the Mark VI system. Mark VI is a gas/steam turbine management system from the Speedtronic line that GE has been developing for more than 30 years with a focus on creating reliable and efficient systems.

IS215VPROH1B serves as an emergency turbine protection module. The IS215VPROH1B provides protection for speed difference detection and backup synchronization check. The board accepts thermocouple and analog inputs. This module has two circuit boards stacked on top of each other. The top plate is an IS200VPRW plate mounted on the bottom plate via four threaded connections. The circuit board consists of an integrated circuit, a transformer, several transistors, as well as resistors, capacitors, and diodes. Capacitors include capacitors made of polyester vinyl. Resistors are sometimes made of carbon composite materials. The circuit board has several inductors and many connectors, including plugs. There is a radiator located on the right front.

The bottom plate of the IS215VPROH1B has two backplanes. It has capacitors, resistors and multiple integrated circuits. This includes oscillating chips. The corners of the top plate are placed near the edge of the board.

The IS215VPROH1B controls the trip solenoid via the TREG board. The application software within the controller is used to initiate the testing of these travel solenoids. These can also be triggered manually.

The IS215VPROH1B is manufactured with a panel. Panel with LED indicator, power switch, cable connector and Ethernet connector. The panel is attached to the circuit board with screws. More information about this module can be found using the original Equipment manufacturer’s publications.

IS215VPROH1BD
