IS220PDIAH1A型號被標記為離散I/O包，與YDIA離散輸入模塊一起用于Mark VI系列。PDIA模型可以使用幾種不同的關聯端子板，其中包括以下內容:
IS200TBCIH4C
IS200STCIH1A
IS200STCIH8A
IS200TBCIH2C
IS200TCIH2A
這些型號都與PDIA一起工作，以批準在危險場所使用。當在危險環境中使用時，需要特定的認證。ULE207685認證用于無危險、I類2區IIC組和I類2區組A、B、C和D位置。當在ATEX 2區IIC組位置使用時，需要特定的認證，認證是UL DEMKO 12 ATEX 1114875X。
IS220PDIAH1A
與Mark VI系列中的其他型號相比，IS220PDIAH1A不一定有特定的面板，因為它是一個I/O包。在設備的正面有7個指示燈，在包裝的右側一組有3個電源指示燈和2個鏈路指示燈，一個指示為ENet1，另一個指示為ENet2。在這三個指示燈下面，有一個以太網端口，用于將模型連接到以太網，以便于以太網通信。
IS220PDIAH1A包具有兩個定位標準，其中兩個是UL 600790 Ed. 5和UL 60079-15 Ed. 3，用于I類2區IIC組。這些信息可以在GEH-6725 Mark VI控制設備Hazloc手冊中找到，該手冊位于手冊標簽下方。
IS220PDIAH1A
The IS220PDIAH1A model is labeled as a discrete I/O package and is used with the YDIA discrete input module in the Mark VI series. The PDIA model can use several different associated terminal boards, including the following:
IS200TBCIH4C
IS200STCIH1A
IS200STCIH8A
IS200TBCIH2C
IS200TCIH2A
These models all work with PDIA for approval for use in hazardous locations. Specific certification is required when used in hazardous environments. ULE207685 certification is used for hazard-free, Class I 2 Zone IIC Group and Class I 2 Zone A, B, C and D locations. When used in the ATEX Zone 2 IIC group location, a specific certification is required, the certification is UL DEMKO 12 ATEX 1114875X.
Compared to other models in the Mark VI series, the IS220PDIAH1A does not necessarily have a specific panel, as it is an I/O package. There are 7 indicators on the front of the device, and on the right side of the package there is a group of 3 power indicators and 2 link indicators, one indicating ENet1 and the other indicating ENet2. Below these three indicators, there is an Ethernet port for connecting the model to Ethernet for easy Ethernet communication.
The IS220PDIAH1A package has two positioning standards, two of which are UL 600790 Ed.5 and UL 60079-15 Ed.3 for Class I Region 2 IIC groups. This information can be found in the GEH-6725 Mark VI Control Device Hazloc Manual, which is located below the manual label.
IS220PDIAH1A
