IS220PPDAH1B板是通用電氣為Mark VIe系統生產的配電系統反饋模型。該模型用于調節板反饋信號，也可以為附加控制器提供以太網接口。這個包的反饋被安排為即插即用，它將使用它插入的電子id來確定所附電源分布模型的功率。來自功率分布模型的信息將繼續用于占用IONet輸出，以提供來自連接的正確反饋。

雖然IS220PPDAH1B包兼容JPDC、JPDS、JPDM和JPDG電源板，但它只兼容來自JPDB、JPDF和JPDE板的反饋信號。通常這種PPDA封裝安裝在以下電路板之一;JPDM、JPDC或JPDS。通過引腳對引腳連接器的接線，使用50引腳帶狀電纜跳線，該包可以潛在地連接到更多的板。

IS220PPDAH1B

自動重新配置是IS220PPDAH1B包的主要操作組件之一。自動重新配置功能允許輕松替換I/O包，因?yàn)樘鎿Q包不需要重新配置。請注意，當自動重新配置正在進行時，在重新配置完成之前，用戶將無法重新啟動。在進行重新配置時，不能進行其他需要進行的下載。

GEIS220PPDAH1B Mark Vle l/O 包IS220PPROS1BIS220PPDAH1B 是 Mak le 下的 /0 包，無背和基于以太網的Mark Vle分布式控制解決方案可提高系統可用性，并簡化整個生命周期的操作和維護。工業互聯網的基礎在很大程度上依賴于以太網傳輸。作為基于機架的控制的替代品，Mak Vle系統在最低級別的控制系統設計中使用這種靈活，高速，低成本的通信。1/0 可以是分布式或集中式的，主控制和安全控制可以在同一網絡上共存，同時保持功能上的獨立性。此外，主控制可以無干擾地監聽安全輸入，從而降低了現場儀表重復的費用，對于 Mark 控件和相關系統的編程、配置、趨勢分析和分析診斷，使用了ControlsT* 軟件套件，其中包括 TooboxST* 應用軟件。它在控制器和工廠級別提供高質量、時間相一致的數據，使控制系統設備得到更有效的管理。

IS220PPDAH1B

The IS220PPDAH1B board is a distribution system feedback model produced by General Electric for the Mark VIe system. This model can be used to adjust the feedback signal of the board, and can also provide Ethernet interface for additional controllers. The feedback of this package is arranged as plug and play, which will use the electronic id it plugs in to determine the power of the attached power distribution model. The information from the power distribution model will continue to be used to occupy the IONet output to provide the correct feedback from the connection.

While the IS220PPDAH1B package is compatible with JPDC, JPDS, JPDM, and JPDG power boards, it is only compatible with feedback signals from JPDB, JPDF, and JPDE boards. Typically, this PPDA package is mounted on one of the following boards; JPDM, JPDC, or JPDS. By wiring a pin-to-pin connector, using a 50-pin ribbon cable jumper, the package can potentially be connected to more boards.

Automatic reconfiguration is one of the main operating components of the IS220PPDAH1B package. The automatic reconfiguration feature allows easy replacement of I/O packages because replacement packages do not need to be reconfigured. Note that while automatic reconfiguration is in progress, the user will not be able to restart until the reconfiguration is complete. No other required downloads can be performed while reconfiguring.

GEIS220PPDAH1B Mark Vle l/O package IS220PPROS1BIS220PPDAH1B is a /0 package under Mak le, the backless and Ethernet-based Mark Vle distributed control solution improves system availability. And simplify operation and maintenance throughout the life cycle. The foundation of the industrial Internet relies heavily on Ethernet transmission. As an alternative to rack-based control, Mak Vle systems use this flexible, high-speed, low-cost communication at the lowest level of control system design. 1/0 can be distributed or centralized, and primary and security controls can coexist on the same network while maintaining functional independence. In addition, the master control can listen for safe inputs without interference, thus reducing the cost of field meter duplication, for the programming, configuration, trend analysis and analytical diagnostics of Mark controls and associated systems, the ControlsT* software suite is used, which includes the TooboxST* application software. It provides high-quality, time-consistent data at the controller and plant level for more efficient management of control system equipment.

IS220PPDAH1B
