IS220PPROH1A是渦輪特定的I/O模塊。它旨在為特定的渦輪現場設備提供直接接口。這種設置消除或減少了以前連接現場設備所需的許多儀器，還提高了運行可靠性，減少了長期維護。IS220PPROH1A通常與TREAH_A終端板一起工作，并用于氣動衍生渦輪緊急跳閘應用。
該組件可以連接到屏障型或盒型端子排。IS220PPROH1A具有電壓傳感的現場布線限制，限制電纜長度為1000英尺的18 AWG布線。值得注意的是，當BPPB P-Pack與BPPC P-Pack交換時，IS220PPROH1A不能自動重新配置。
IS220PPROH1A
IS220PPROH1A的前面板上標有組件id號和幾個LED指示燈。它們成對地放在前面板上。第一對被標記為PWR/ATTN，第二個LINK/TxRx和ENET 1，第三個LINK/TxRx和ENET2。最終組件位于面板的底部;這被標記為IR端口。
IS220PPROH1A接受三種速度信號。這包括減速、加速和超速。該組件還具有實現超速的硬件。該包通過一套全面的反饋信號監測選定的旅行板的狀態和操作。該包支持TMR和單工備份保護。
IS220PPROH1A
The IS220PPROH1A is a turbine-specific I/O module. It is designed to provide a direct interface for specific turbine field equipment. This setup eliminates or reduces many of the instruments previously required to connect field equipment, and also improves operational reliability and reduces long-term maintenance. The IS220PPROH1A typically works with the TREAH_A terminal board and is used in pneumatically derived turbine emergency trip applications.
The component can be connected to a barrier or box terminal block. The IS220PPROH1A has field wiring limitations for voltage sensing, limiting 18 AWG wiring to 1000 feet of cable length. It is worth noting that IS220PPROH1A cannot be automatically reconfigured when BPPB P-Pack is exchanged with BPPC P-Pack.
The front panel of the IS220PPROH1A is marked with the component id number and several LED indicators. They are placed in pairs on the front panel. The first pair is labeled PWR/ATTN, the second LINK/TxRx and ENET 1, and the third LINK/TxRx and ENET2. The final assembly is located at the bottom of the panel; This is labeled as an IR port.
The IS220PPROH1A accepts three speed signals. This includes deceleration, acceleration and speeding. The component also has hardware to enable overspeed. The package monitors the status and operation of the selected travel board through a comprehensive set of feedback signals. The package supports TMR and simplex backup protection.
IS220PPROH1A
