產品描述
is420ucsh1a控制器是通用電氣制造的第一個UCSB控制器，是Mark VIe控制安全系統系列的一部分。該控制器類似于UCSC控制器，雖然它沒有相同的硬件，但操作該控制器所需的軟件幾乎相同。根據GEH-6725 Mark VIe和Mark VIeS，控制設備HazLoc指令指南IS420UCSBH1A控制器被標記為Mark VIe, LS2100e和EX2100e控制器。這個控制器還有一個特定的微處理器，安裝在這個設備上的微處理器是600 MHz的EP80579英特爾處理器。
在GEH-6725指令指南的第22頁上，有一個小表格，標記了為is420ucsh1a供電所需的電氣/電源額定值，額定值如下，最小電壓為18直流，最大直流電為30伏，標稱額定值為24伏和28伏直流電。該器件使用的最大額定電流為1.5 ADC。
IS420UCSBH1A
安裝時，需要在危險和非危險場所安裝is420ucsh1a控制器。例如，當安裝在ATEX Zone 2, Group IIC中時，需要的認證是UL DEMKO 12 ATEX 1114875X。所有關于安裝在I類，2區，IIC組，無害和I類，2分區，組，A, B, C和D的控制器的認證都是相同的，這些位置的認證要求是UL E207685。
is420ucsh1a綜述
IS420UCSBH1A控制器是一個高度可靠和通用的模塊，因?yàn)樗膲勖图嫒菪訣X2100e, LS2100e，和馬克VI系統。它有一個低故障率，是可修復的，因?yàn)樗婕暗酱蠖鄶?shù)缺陷
IS420UCSBH1A
Product description
The is420ucsh1a controller is the first UCSB controller manufactured by GE and is part of the Mark VIe family of Control safety Systems. The controller is similar to the UCSC controller, although it does not have the same hardware, the software required to operate the controller is nearly the same. According to GEH-6725 Mark VIe and Mark VIeS, Control Devices HazLoc Directive Guidelines IS420UCSBH1A controllers are labeled Mark VIe, LS2100e and EX2100e controllers. This controller also has a specific microprocessor, the microprocessor installed on this device is a 600 MHz EP80579 Intel processor.
On page 22 of the GEH-6725 Instruction Guide, there is a small table marked with the electrical/power ratings required to power the is420ucsh1a, the ratings are as follows, minimum voltage is 18 DC, maximum DC is 30 volts, and nominal ratings are 24 volts and 28 volts DC. The device uses a maximum rated current of 1.5 ADC.
The is420ucsh1a controller must be installed in hazardous and non-hazardous places. For example, when installed in ATEX Zone 2, Group IIC, the required certification is UL DEMKO 12 ATEX 1114875X. All certifications regarding controllers installed in Class I, Zone 2, IIC Group, Harmless and Class I, Zone 2, Group, A, B, C and D are the same, and the certification requirements for these locations are UL E207685.
Overview of is420ucsh1a
The IS420UCSBH1A controller is a highly reliable and versatile module due to its lifetime and compatibility with EX2100e, LS2100e, and Mark VI systems. It has a low failure rate and is repairable as it relates to most defects
IS420UCSBH1A
