高效功率轉換
寬輸入電壓范圍
過載和短路保護
緊湊輕巧的設計
易于安裝和維護
技術規格
輸入電壓范圍:90-264 VAC
輸出電壓范圍:12- 48vdc
輸出電流范圍:0.5-10A
效率:90%

MP3010

MP-3000系列電動機保護繼電器是一種多功能的基于微處理器的保護繼電器，用于在所有電壓等級下保護任何尺寸的電動機。它最常用于中壓啟動器和臨界或更大的電機。這個繼電器是一個電流唯一的設備，提供完整和可靠的電機保護，監測和啟動控制功能。它有固定安裝、半嵌入式或半嵌入式快速釋放抽出式兩種形式。兩種外殼都很緊湊，適合標準的IQ切割。可選的快速釋放抽出式外殼具有兩級觸點斷開和自短路ct電路端子。備用自短路端子對可用作繼電器移除警報或繼電器移除時的連續電機運行(非故障安全模式)可選通信模塊外部安裝在固定安裝殼體上，內部安裝在抽出式殼體中。
工作溫度范圍:-40℃~ +70℃
保護:過載、短路、過壓、過溫
工業自動化
電信
網絡
醫療設備
測試及測量設備

本文檔提供了有關伊頓公司生產的MP3010產品的詳細信息。MP3010是一款多功能可靠的電源管理器件，專為各種應用而設計。

MP3010

High efficiency power conversion
Wide input voltage range
Overload and short circuit protection
Compact and lightweight design
Easy to install and maintain
Technical specification
Input voltage range :90-264 VAC
Output voltage range: 12-48vdc
Output current range :0.5-10A
Efficiency :90%
The MP-3000 Series Motor Protection relay is a versatile microprocessor-based protective relay designed to protect motors of any size at all voltage levels. It is most commonly used in medium voltage starters and critical or larger motors. This relay is a current only device that provides complete and reliable motor protection, monitoring and starting control functions. It comes in two forms: fixed mounting, semi-embedded or semi-embedded quick release extraction. Both enclosures are compact and suitable for standard IQ cuts. Optional quick-release pull-out housing with two-stage contact break and self-shorting ct circuit terminals. The spare self-shorting terminal pair can be used as relay removal alarm or continuous motor operation when the relay is removed (non-fail-safe mode) The optional communication module is externally mounted in a fixed mounting housing and internally mounted in a pull-out housing.
Operating temperature range :-40℃~ +70℃
Protection: overload, short circuit, over voltage, over temperature
Industrial automation
telegraphy
network
Medical equipment
Test and measurement equipment

This document provides detailed information about the MP3010 products manufactured by Eaton. The MP3010 is a versatile and reliable power management device designed for a variety of applications.

MP3010
