低功耗，適用于各種高性能微處理器
應用程序
MVME2400系列VME板提供摩托羅拉PowerPlus II架構的性能和完全定制的能力，以滿足需求
您的應用程序需要兩個PCI mezz卡。的靈活性
的MVME2400提供了一個優秀的基礎平臺，可以快速
并且可以輕松定制各種特定于行業的應用程序。
利用摩托羅拉的低功耗，高性能的PowerPC 750微處理器，外圍組件互連(PCI)總線為板載
外設，處理器/存儲器總線到PCI總線橋接，以及VME接口;
MVME2400處理器模塊將最佳水平的靈活性和性能集成到單個VME插槽中。
符合IEEE P1386.1的PMC插槽
MVME2400具有雙PMC端口，支持
前面板和P2 I/O。P2基于I/ o的pmc
使用時PMC委員會對PCI I/O的建議
VME64擴展連接器將引腳兼容
用MVME2400。
除了提供高性能擴展I/O之外，
符合IEEE P1386.1標準的PMC端口構成了未來幾代產品的通用架構。更改I/O需求可以通過簡單地替換pmc來滿足
重用相同的基礎平臺，降低長期成本
的所有權。

MVME2400

VME64擴展連接器
為了最大限度地提高M(jìn)VME2400的能力，5排160-
引腳DIN連接器取代了VME歷來用于P1和P2的3排96引腳連接器。兩行，Z和D，
在VME P1/J1和P2/J2連接器中添加了什么
為用戶提供額外的I/O。VME64擴展
連接器100%向后兼容現有的VME
卡系統。
第二代架構，PowerPlus II架構
處理器和總線架構是否完全優化以獲得
PowerPC微處理器的最大性能
PCI總線和VMEbus。添加到
原始的PowerPlus架構包括對100mhz的支持
本地總線操作，以及同步DRAM的使用
(SDRAM)技術。VME的卓越性能
基于PowerPlus II架構的處理器板
不是單一因素造成的。設計中的許多元素
PowerPlus II架構的杰出貢獻
性能，包括處理器/內存子系統，
高速本地總線，最佳解耦架構，
將處理器與PCI解耦，以及先進的VME
接口，減少PCI延遲。

MVME2400

Low power consumption, suitable for a variety of high-performance microprocessors
Application program
The MVME2400 Series VME board offers the performance of the MOTOROLA PowerPlus II architecture and the ability to be fully customized to meet the needs
Your application requires two PCI mezz cards (pmc). Flexibility of
The MVME2400 provides an excellent foundation platform that can be fast
And a variety of industry-specific applications can be easily customized.
Utilizing MOTOROLA’s low-power, high-performance PowerPC 750 microprocessor, the Peripheral Component Interconnect (PCI) bus is onboard
Peripherals, processor/memory bus to PCI bus bridge, and VME interface;
The MVME2400 processor module integrates the best level of flexibility and performance into a single VME slot.
PMC slot compliant with IEEE P1386.1
The MVME2400 has dual PMC ports and supports
Front panel and P2 I/O. P2 I/ O-based pmc
PMC Committee recommendations for PCI I/O when used
The VME64 expansion connector will be pin-compatible
Use MVME2400.
In addition to delivering high-performance extended I/O,
The IEEE P1386.1 compliant PMC port forms the common architecture for future generations of products. Changing I/O requirements can be met by simply replacing the pmc
Reuse the same underlying platform to reduce long-term costs
The ownership of.

VME64 expansion connector
To maximize the capabilities of the MVME2400, 5 rows 160-
The pin DIN connector replaces the 3-row 96-pin connector that VME has historically used for P1 and P2. Two lines, Z and D,
What has been added to the VME P1/J1 and P2/J2 connectors
Additional I/O for users. VME64 extension
Connectors are 100% backward compatible with existing Vmes
The card system.
Second generation architecture, PowerPlus II architecture
Whether the processor and bus architecture is fully optimized to obtain
Maximum performance of PowerPC microprocessors
PCI bus and VMEbus. Append to
The original PowerPlus architecture included support for 100mhz
Local bus operation, and the use of synchronous DRAM
(SDRAM) technology. Exceptional performance of VME
Processor board based on PowerPlus II architecture
No single factor is to blame. Many elements in the design
Outstanding contribution of PowerPlus II architecture
Performance, including processor/memory subsystem,
High speed local bus, best decoupled architecture,
Decouple the processor from PCI, and advanced VME
Interface to reduce PCI latency.

MVME2400
