產品特性
高達1.3 GHz的系統級NXP?MPC864xD具有雙PowerPC?e600處理器內核，雙集成內存控制器，DMA引擎，PCI Express接口，以太網和本地I/O
VxWorks、LynxOS和Linux的單板支持包
2eSST VMEbus協議，跨VMEbus傳輸速率為320MB/s
高達2GB的DDR2 ECC內存，128MB NOR閃存和2,4或8GB NAND閃存
4個千兆以太網接口
USB 2.0控制器，用于集成具有成本效益的外設(僅限商業溫度)
雙33/66/100MHz PMC-X站點，通過支持處理器pmc的行業標準模塊進行擴展
8x PCI Express擴展連接器，用于PMC-X和XMC擴展，使用SMART EC XMCspan

MVME7100

MVME7216E RTM (direct-connect rear transition module)，用于VMEbus機箱后部的I/O路由
可擴展溫度(-40°C至+71°C)和堅固耐用的板變體
產品信息
項目/部件號mvme7100
項目描述mvme7100 NXP?MPC864xD VME單板計算機
MVME7100采用MPC864xD處理器，為使用前幾代VME(特別是MPC74xx)的VME客戶提供了一條增長路徑。與其他架構相比，它具有出色的功耗/熱、可靠性和生命周期優勢。
架構vme, VME64x
冷卻空氣冷卻
高度6u
型號mvme7100
rohs是的
垂直市場防御/航空航天
技術信息
板高6u
單板類型sbc
CPU類型nxp

MVME7100

MVME7100

Product Features
Up to 1.3 GHz system-on-chip NXP? MPC864xD with dual PowerPC? e600 processor cores, dual integrated memory controllers, DMA engine, PCI Express interface, Ethernet, and local I/O
Board support packages for VxWorks, LynxOS, and Linux
2eSST VMEbus protocol with 320MB/s transfer rate across the VMEbus
Up to 2GB of DDR2 ECC memory, 128MB NOR flash and 2, 4 or 8GB NAND flash
Four Gigabit Ethernet ports
USB 2.0 controller for integrating cost-effective peripherals (commercial temperature only)
Dual 33/66/100MHz PMC-X sites for expansion via industry standard modules with support for processor PMCs
8x PCI Express expansion connector for PMC-X and XMC expansion using SMART EC XMCspan
MVME7216E direct-connect rear transition module (RTM) for I/O routing through rear of a VMEbus chassis
Extended temperature (-40°C to +71°C) and rugged board variants available
Product Information
Item/Part Number MVME7100
Item Description MVME7100 NXP? MPC864xD VME Single Board Computer
Extended Description The MVME7100 features the MPC864xD processor and offers a growth path for VME customers using previous generations of VME, specifically MPC74xx. It offers excellent power/thermal, reliability and lifecycle advantages over other architectures.
Architecture VME, VME64x
Cooling Air-Cooled
Height 6U
Model Number MVME7100
RoHs Yes
Vertical Market Defense/Aerospace
Technical Information
Board Height 6U
Board Type SBC
CPU Type NXP
