ABB PM860 AC 800M控制器模塊AC 800M控制器和所有模塊的通信接口
AC 800M是一系列軌裝模塊，由CPU、通信模塊、電源模塊和各種附件組成。有幾個CPU模塊可供選擇，從中等處理器能力和低成本到高處理器能力和支持完全冗余。
PM860A控制器的底板有兩個RJ45以太網端口(CN1、CN2)用于連接到控制網絡，以及兩個RJ45串行端口(COM3、COM4)。其中一個串行端口(COM3)是帶有調制解調器控制信號的RS-232C端口而另一個端口(COM4)則被隔離并用于連接配置工具。
簡單DIN軌道連接/卸料程序，使用唯一的滑道&鎖機構。所有base plates都有唯一的以太網地址，每個CPU都有一個硬件標識。地址可以在連接到TP830 base plate的以太網地址標簽上找到

PM860

PM851AK01-EA控制器的底板有兩個用于連接控制網絡的RJ45以太網端口(CN1、CN2)和兩個RJ45串行端口(COM3、COM4)。其中一個串行端口(COM3)是帶有調制解調器控制信號的RS-232C端口，而另一個端口(COM4)是隔離的，用于連接配置工具簡單的DIN導軌連接/拆卸程序，使用獨特的滑動和鎖定機制。所有基板都有一個唯一的以太網地址，為每個CPU提供一個硬件標識。該地址可在TP830底板上的以太網地址標簽上找到。

特點和優勢

可靠性和簡單的故障診斷程序

模塊化，允許逐步擴展

IP20級保護，無需外殼

控制器可以用800xA控件生成器進行配置

控制器具有完全EMC認證的PM856控制器模塊

基于最佳通信連接標準的硬件(以太網、PROFIBUS DP等)。)

PM860

ABB PM860 AC 800M controller module Communication port between the AC 800M controller and all modules
The AC 800M is a series of rail-mounted modules consisting of a CPU, communication module, power module and various accessories. There are several CPU modules to choose from, ranging from medium processor power and low cost to high processor power and support for full redundancy.
The baseplate of the PM860A controller has two RJ45 Ethernet ports (CN1, CN2) for connecting to the control network, and two RJ45 serial ports (COM3, COM4). One of the serial ports (COM3) is the RS-232C port with the modem control signal while the other port (COM4) is isolated and used to connect to the configuration tool.
Simple DIN rail connection/discharge procedure with unique slide & lock mechanism. All base plates have a unique Ethernet address, and each CPU has a hardware ID. The address can be found on the Ethernet address label connected to the TP830 base plate

The baseboard of the PM851AK01-EA controller has two RJ45 Ethernet ports (CN1 and CN2) and two RJ45 serial ports (COM3 and COM4) for connecting to the control network. One of the serial ports (COM3) is an RS-232C port with a modem control signal, while the other port (COM4) is isolated and is used to connect the configuration tool’s simple DIN rail connection/removal procedure using a unique sliding and locking mechanism. All baseboards have a unique Ethernet address, giving each CPU a hardware identity. This address can be found on the Ethernet address label on the TP830 baseboard.

Characteristics and advantages

Reliable and simple troubleshooting program

Modular, allowing for gradual expansion

IP20 protection, no case required

The controller can be configured with the 800xA control generator

Controller with fully EMC certified PM856 controller module

Hardware based on the best communication connectivity standards (Ethernet, PROFIBUS DP, etc.).

PM860
