PM860A控制器的底板有兩個RJ45以太網端口(CN1、CN2)用于連接到控制網絡，以及兩個RJ45串行端口(COM3、COM4)。其中一個事行端口(COM3)是帶有調制解調器控制信號的RS-232C端口而另一個端口(COM4)則被隔離并用于連接配置工具。
簡單DIN軌道連接/卸料程序，使用唯一的滑道&鎖機構。所有base plates都有唯一的以太網地址，每個CPU都有一個硬件標識。地址可以在連接到TP830 base plate的以太網地址標簽上找到

PM860K01

全球商業別名:PM860K01
產品編號:3 bse018100r1
ABB型號:PM860K01
目錄說明:處理器單元套件
技術信息:PM860K01處理器單元套件
包包括:
-PM860、CPU
-TP830，底板，寬度=115毫米
-TB850, cex總線終結者
-TB807, ModuleBus終止器
內存?zhèn)溆秒姵?943013-6
– 4個電源插頭3BSC840088R4
交換號EXC3BSE018100R1
產品凈重:1.1 kg
稅號:85389091

PM860K01

The baseplate of the PM860A controller has two RJ45 Ethernet ports (CN1, CN2) for connecting to the control network, and two RJ45 serial ports (COM3, COM4). One of the transaction ports (COM3) is the RS-232C port with the modem control signal while the other port (COM4) is isolated and used to connect to the configuration tool.
Simple DIN rail connection/discharge procedure with unique slide & lock mechanism. All base plates have a unique Ethernet address, and each CPU has a hardware ID. The address can be found on the Ethernet address label connected to the TP830 base plate
Global business alias :PM860K01
Product Number :3 bse018100r1
ABB model :PM860K01
Directory Description: Processor unit suite
Technical information :PM860K01 processor unit Kit
The package includes:
-PM860 and CPU
-TP830, base plate, width =115 mm
-TB850, cex bus Terminator
-TB807: ModuleBus terminator
Memory Spare battery 4943013-6
– 4 power plugs 3BSC840088R4
Exchange number EXC3BSE018100R1
Net weight: 1.1kg
Tax code :85389091

PM860K01
