PXIe-8840是一款用于PXI系統的嵌入式控制器，適用于處理器密集型、模塊化儀器和數據采集應用。PXIe-8840包含兩個10/100/1000BASE-TX（千兆位）以太網端口、兩個USB 3.0端口和四個USB 2.0端口以及一個集成硬盤驅動器、串行端口和其他外設I/O。該模塊是款由兩家公司共同合作下，結合labview的易操作性和ARM微處理器性能的產品。ARM是主要的32位嵌入式精簡指令集處理器供應商，目前占有超過75%的市場份額以及超過100億的ARM核設備。當使用該新模塊，工程師和科學人員可以在labview環境下創建嵌入式應用并且把它們應用在由arm授權的微處理器ip創建的多達260個的微處理控制器上。這些微處理器是由世界主要的半導體公司，例如 adi公司(analog devices)，流明諾瑞公司(luminary micro), 恩智浦公司, 飛思卡爾半導體公司(freescale semiconductor), 英特爾公司和德州電器(texas instruments)所生產的。

微控制器是集成的微處理器，其包括存儲器，外圍接口和接口，以及裝在單個芯片上的cpu。微控制器由此成為嵌入式系統的一種解決方案，在需要對激勵有實時響應的控制和中斷驅動應用中十分理想。從garmin nuvi便攜導航設備等消費品到biac便攜肌肉刺激器等工業和醫學，ARM微控制器能夠提供一個很廣領域的應用。

PXIE-8840

labview針對ARM微處理器的嵌入式模塊具有l(wèi)abview驅動功能，幫助該領域在圖形化界面下完成對ARM微處理器所有控件的編程，包括模擬和數字i/o。該模塊還具有桌面模擬能力的功能，這樣用戶就能夠在他們的臺式電腦上運行開發的適用于ARM微控制器的程序，而不借助任何其他硬件。工程師和科學家可以借助ni multisim，交互式spice仿真和電路分析軟件來使用桌面仿真模擬出一個真實的嵌入式系統設計仿真環境的整個信號設計鏈。

ARM微處理器中l(wèi)abview嵌入式模塊的其他功能還包括一個項目向?qū)?，能夠自動配置和安裝，幫助用戶快速建立項目，同時在特定硬件中止情況發生的時候，能夠通過建立labview代碼運行來簡化中斷驅動編程，從而實現中斷管理。除了軟件之外，NI還提供一個開發工具包，其選擇包括裝有基于arm 7系列nxp處理器的mcb2370評估板系統或者基于cortex-m3處理器開發的luminary微處理器stellaris lm3s8962。

微控制器是集成的微處理器，其包括存儲器，外圍接口和接口，以及裝在單個芯片上的cpu。微控制器由此成為嵌入式系統的一種解決方案，在需要對激勵有實時響應的控制和中斷驅動應用中十分理想。從garmin nuvi便攜導航設備等消費品到biac便攜肌肉刺激器等工業和醫學，ARM微控制器能夠提供一個很廣領域的應用。

PXIE-8840

The PXIe-8840 is an embedded controller for PXI systems for processor-intensive, modular instrumentation and data acquisition applications. The PXIe-8840 includes two 10/100/1000BASE-TX (Gigabit) Ethernet ports, two USB 3.0 ports and four USB 2.0 ports, as well as an integrated hard drive, serial ports and other peripheral I/O. The module is a collaboration between the two companies that combines the ease of use of labview with the performance of an ARM microprocessor. ARM is the leading supplier of 32-bit embedded Reduced instruction set (risc) processors, with more than 75% market share and more than 10 billion ARM-core devices. With the new module, engineers and scientists can create embedded applications in the labview environment and apply them to up to 260 microprocessing controllers created with ARM-licensed microprocessor ip. These microprocessors are manufactured by the world’s major semiconductor companies, such as analog devices, It is manufactured by luminary micro, nxp, freescale semiconductor, intel and texas instruments.

A microcontroller is an integrated microprocessor that includes memory, peripheral interfaces and interfaces, and a cpu on a single chip. Microcontrollers thus become a solution for embedded systems, ideal for control and interrupt drive applications that require a real-time response to incentives. From consumer products such as garmin nuvi portable navigation devices to industrial and medical applications such as biac portable muscle stimulators, ARM microcontrollers offer a wide range of applications.

labview Embedded modules for ARM microprocessors feature labview drivers that help the field program all controls of ARM microprocessors, including analog and digital i/o, under a graphical interface. The module also has the capability of desktop emulation, so that users can run programs developed for ARM microcontrollers on their desktop computers without the aid of any other hardware. Engineers and scientists can use ni multisim, interactive spice simulation and circuit analysis software to simulate the entire signal design chain of a real embedded system design simulation environment using desktop simulation.

Additional features of the labview embedded module in the ARM microprocessor include a project wizard that can automatically configure and install to help users quickly set up projects, and can simplify interrupt driver programming by setting up labview code to run when a specific hardware abort occurs, thus achieving interrupt management. In addition to the software, NI also offers a development kit with options including the mcb2370 evaluation board system with an arm 7-series nxp processor or the luminary microprocessor stellaris lm3s8962 based on a cortex-m3 processor.

A microcontroller is an integrated microprocessor that includes memory, peripheral interfaces and interfaces, and a cpu on a single chip. Microcontrollers thus become a solution for embedded systems, ideal for control and interrupt drive applications that require a real-time response to incentives. From consumer products such as garmin nuvi portable navigation devices to industrial and medical applications such as biac portable muscle stimulators, ARM microcontrollers offer a wide range of applications.

PXIE-8840
