SCXI-1193可實現以下拓撲結構:四路8 x 1多路復用器、四路4 x 1端接多路復用器、雙路16 x 1多路復用器、雙路8 x 1端接多路復用器、32 x 1多路復用器、16 x 1端接多路復用器和獨立模塊。
這射頻多路復用器開關模塊可用于多種不同的電纜。這些電纜包括:MCX-MCX電纜、MCX-BNC電纜、MCX-SMB電纜或MCX-SMA電纜。每根電纜都有0.3米或1.0米長。還有一個50歐姆的MCX終端可用。

SCXI-1193
當50歐姆MCX終端位于32個通道的一半時,用戶可以將該模塊用作端接多路復用器。該器件的DC功率要求為:50毫安時為+5伏直流電,170毫安時為+18.5伏至+25伏直流電,170毫安時為-18.5伏至-25伏直流電。
這NI SCXI-1193模塊有36個用于I/O連接器的MCX插孔,2個用于觸發連接器的SMB插孔,由銀鈀和金制成的繼電器,最大掃描速率為每秒100次操作。該裝置為機電閉鎖繼電器類型。NI設備重2盎司,尺寸為1.2 x 6.8 x 7.8英寸。在物理維度上。它的推薦工作溫度范圍為0°C至50°C,儲存溫度范圍為-20°C至70°C,非冷凝濕度范圍為5%至85%。

SCXI-1193
The SCXI-1193 can implement the following topologies: four-way 8 x 1 multiplexer, four-way 4 x 1 terminated multiplexer, dual-way 16 x 1 multiplexer, dual-way 8 x 1 terminated multiplexer, 32 x 1 multiplexer, 16 x 1 terminated multiplexer, and standalone modules.
This RF multiplexer switch module can be used for a variety of different cables. These cables include :MCX-MCX cable, MCX-BNC cable, MCX-SMB cable, or MCX-SMA cable. Each cable is 0.3 or 1.0 meters long. A 50 ohm MCX terminal is also available.
When the 50 ohm MCX terminal is located in half of the 32 channels, the user can use the module as an end multiplexer. The DC power requirements for this device are: +5 volts DC at 50 mA, +18.5 volts DC to +25 volts DC at 170 MA, and -18.5 volts DC to -25 volts DC at 170 Ma.
This NI SCXI-1193 module has 36 MCX jacks for I/O connectors, 2 SMB jacks for triggering connectors, relays made of silver palladium and gold, and a maximum scan rate of 100 operations per second. The device is of electromechanical latching relay type. The NI device weighs 2 ounces and measures 1.2 x 6.8 x 7.8 inches. In the physical dimension. It has a recommended operating temperature range of 0°C to 50°C, a storage temperature range of -20°C to 70°C, and a non-condensing humidity range of 5% to 85%.

SCXI-1193
