制造商:ABB
產品編號:3BSE018173R1
產品型號:SM811K01安全CPU模塊
協作安全CPU。
通過BC810 CEX總線互連盒連接到CEX總線。
包括:- SM811、安全模塊- TP868、底板- TK852V10、安全CPU與PM865之間的同步連接電纜。
產品凈重:0.6公斤
裝運重量:1.6千克
CPU模塊的工作電壓一般是5V，而PLC的輸入／輸出信號電壓一般較高，如直流24V和溝通220V。從外部引進的尖峰電壓和攪擾噪聲可能損壞CPU模塊中的元器件，或使PLC不能正常工作。在I／O模塊中，用光耦合器、光電晶閘管、小型繼電器等器件來阻隔PLC的內部電路和外部的I／O電路，I／O模塊除了傳遞信號外，還有電平轉換與阻隔的效果。
SM811K01
Manufacturer :ABB
Product Number :3BSE018173R1
Product model :SM811K01 Secure CPU module
Collaborative security CPU.
Connect to the CEX bus through the BC810 CEX bus interconnect box.
These cables include :- SM811, security module – TP868, baseboard – TK852V10, and synchronization cables between the security CPU and PM865.
Net weight: 0.6kg
Shipping weight: 1.6kg
The operating voltage of the CPU module is generally 5V, while the input/output signal voltage of the PLC is generally higher, such as 24V DC and 220V communication. The surge voltage and interference noise introduced from outside can damage the components in the CPU module or make the PLC not work properly. In the I/O module, optical couplers, photoelectric thyristors, small relays and other devices to block the PLC’s internal circuit and external I/O circuit, I/O module in addition to transmitting signals, there are level conversion and blocking effects.
SM811K01
