產品說明
489-P5-LO-A20-E是通用電氣SR系列繼電器中的阿格多線繼電器(與通用電氣多線469電機保護繼電器和通用電氣多線735饋線保護繼電器屬于同一系列)。)489-P5-LO-A20-E設計用于發電機保護，可用于感應或同步發電機。該裝置可在25、50或60赫茲下運行。

489-P5-LO-A20-E設計有40個字符的顯示屏，允許用戶查看數值信息、診斷和設定值。前面板包括數字鍵盤、狀態指示器、數值上下鍵、RS232端口接口以及控制和編程鍵，包括復位、輸入、菜單、菜單向上和菜單向下鍵。這允許在不連接外部計算機的情況下進行控制。

背板包括12個RTD輸入、6個輸出繼電器、2個RS485通信端口和4個VT輸入。RTD可現場編程。通信端口可以使用高達19200 bps的ModbusRTU或DNP 3.0協議(或兩者都使用)。

489-P5-LO-A20-E的背板還包括四個隔離的4-20 mA模擬輸入和輸出以及七個可分配的數字輸入。有七個CT輸入用于三相輸出/三相零線和接地電流檢測，以及一個獨立的安全和濾波器接地。489-P5-LO-A20-E上的所有輸入滿足SWC、C37.990 EMI、RFI抗干擾性。

SR489-P5-LO-A20-E

Product description
489-P5-LO-A20-E is an Agdo wire relay in the GE SR series of relays (in the same family as GE Multiwire 469 motor protection relays and GE Multiwire 735 feeder protection relays). The 489-P5-LO-A20-E is designed for generator protection and can be used in induction or synchronous generators. The device can operate at 25, 50 or 60 Hertz.

The 489-P5-LO-A20-E is designed with a 40-character display that allows users to view numerical information, diagnostics, and set values. The front panel includes a numeric keypad, status indicator, numerical up and down keys, RS232 port interfaces, and control and programming keys including reset, input, menu, menu Up, and menu Down keys. This allows control without being connected to an external computer.

The backplane includes 12 RTD inputs, 6 output relays, 2 RS485 communication ports, and 4 VT inputs. RTD is field programmable. Communication ports can use ModbusRTU or DNP 3.0 protocols up to 19200 bps (or both).

The 489-P5-LO-A20-E’s backplane also includes four isolated 4-20 mA analog inputs and outputs and seven assignable digital inputs. There are seven CT inputs for three-phase output/three-phase neutral line and ground current detection, as well as a separate safety and filter ground. All inputs on 489-P5-LO-A20-E meet SWC, C37.990 EMI, RFI anti-interference.

SR489-P5-LO-A20-E

SR489-P5-LO-A20-E
