ICS TRIPLEX T8231 可信電源系統
ICS TRIPLEX T8231 可信電源系統
可信電源系統是一種高密度的靈活電源，設計用于轉換110 Vac或240 Vac的干線電壓?？尚刨嚠a(chǎn)品的輸出為24 Vdc或24 Vdc可調現場電源。
可信電源系統由一個帶機械支撐的1U電源架組成，包含多達三個750 W的電源組。電源組在使用一個或多個電源架的配置中分擔負載。每個電源組都有一個單獨的電源連接，通過一個機械保持的交叉型連接器。每個電源架可以提供2250 W的功率或1500 W的功率，n+1元余來自單個電源?？梢赃B接多個單元，以滿足進一步的容量或幾余要求

T8231

電源組狀態的診斷信息通過電源端口提供，該端口連接到電源架的后部。該設備監控輸入和輸出條件，并使用繼電器觸點報告超量程故障和超溫/風扇故障。電源端口還允許連接可選的機架安裝電源控制器，用于輸出電壓和電流的實時配置，監控4個電源架中多達12個電源組
系統配置工具支持MODBUS TCP的單元ID 0至255
在選擇以太網和端口502的情況下配置MODBUS TCP時
如果選擇，則可以為單元ID設置0到255范圍內的值。
此前，這一數字僅限于1比247。
受信任的工具集套件改進
Trusted中已經實施了許多改進
工具集套件：
?修復了功能框圖程序中的錯誤行為
?修復了復雜密碼配置的問題
?修復了許多用戶界面問題
Modbus從站，TCP單元標識符的使用
選擇了以太網和端口502的MODBUS TCP從機
在0到255范圍內的值可以用于單元ID。以前這個
被限制為1比247。
8000系列/CS300混合數字輸入單槽熱修復
CS300數字輸入模塊現已通過熱修復進行更換

T8231

ICS TRIPLEX T8231 Trusted Power System
ICS TRIPLEX T8231 Trusted Power System
The Trusted Power system is a high density flexible power supply designed to convert main line voltages of 110 Vac or 240 Vac. The output of the trusted product is 24 Vdc or 24 Vdc adjustable field power supply.
The Trusted Power system consists of a mechanically supported 1U power rack containing up to three 750 W power packs. Power packs share the load in a configuration that uses one or more power racks. Each power pack has a separate power connection via a mechanically held cross-type connector. Each power rack can provide 2250 W of power or 1500 W of power, with n+1 yuan remaining from a single power supply. Multiple units can be connected to meet further capacity or redundancy requirements
The diagnostic information about the status of the power supply group is provided through the power port, which is connected to the rear of the power supply rack. The device monitors input and output conditions and uses relay contacts to report overrange failures and overtemperature/fan failures. The power port also allows the connection of an optional rack-mounted power controller for real-time configuration of output voltage and current, monitoring up to 12 power packs in 4 power racks
The system configuration tool supports MODBUS TCP unit ids 0 to 255
When configuring MODBUS TCP with Ethernet and port 502 selected
If selected, you can set a value from 0 to 255 for the cell ID.
Previously, the number was limited to one to 247.
Trusted toolset suite improvements
Many improvements have been implemented in Trusted
Toolset suite:
? Fixed bug behavior in the function block diagram program
? Fixed an issue with complex password configurations
? Fixed many user interface issues
Modbus slave station, TCP unit identifier used
Ethernet and MODBUS TCP slave on port 502 are selected
Values in the range 0 to 255 can be used for cell ids. Previous this
Is limited to 1 to 247.
8000 Series /CS300 Hybrid digital input Single slot hot repair
The CS300 digital input module has now been replaced by hot repair

T8231
