制造商:ICS Triplex
產(chǎn)品編號:T8310
產(chǎn)品類型:可信TMR擴展器接口
電壓范圍:20至32V直流電
散熱:40W
與機箱一起使用:T8300
最大負載:40W
模塊時鐘:50兆赫
擴展器總線數(shù)據(jù)速率:250Mbps
制造商:ICS Triplex
/O接口:擴展器機箱背板
工作溫度:-5攝氏度至60攝氏度(13華氏度至140華氏度)非工作溫度:-25攝氏度至70攝氏度(-25華氏度至158華氏度工作濕度:5至95%相對濕度
尺寸(長x寬x高):30.3厘米x 3.1厘米x 26.cm厘米
重量:1.14千克
運輸重量:3公斤

T8310

ICS TRIPLEX T8231 Trusted Power System
ICS TRIPLEX T8231 Trusted Power System
The Trusted Power system is a high density flexible power supply designed to convert main line voltages of 110 Vac or 240 Vac. The output of the trusted product is 24 Vdc or 24 Vdc adjustable field power supply.
The Trusted Power system consists of a mechanically supported 1U power rack containing up to three 750 W power packs. Power packs share the load in a configuration that uses one or more power racks. Each power pack has a separate power connection via a mechanically held cross-type connector. Each power rack can provide 2250 W of power or 1500 W of power, with n+1 yuan remaining from a single power supply. Multiple units can be connected to meet further capacity or redundancy requirements
The diagnostic information about the status of the power supply group is provided through the power port, which is connected to the rear of the power supply rack. The device monitors input and output conditions and uses relay contacts to report overrange failures and overtemperature/fan failures. The power port also allows the connection of an optional rack-mounted power controller for real-time configuration of output voltage and current, monitoring up to 12 power packs in 4 power racks
The system configuration tool supports MODBUS TCP unit ids 0 to 255
When configuring MODBUS TCP with Ethernet and port 502 selected
If selected, you can set a value from 0 to 255 for the cell ID.
Previously, the number was limited to one to 247.
Trusted toolset suite improvements
Many improvements have been implemented in Trusted
Toolset suite:
? Fixed bug behavior in the function block diagram program
? Fixed an issue with complex password configurations
? Fixed many user interface issues
Modbus slave station, TCP unit identifier used
Ethernet and MODBUS TCP slave on port 502 are selected
Values in the range 0 to 255 can be used for cell ids. Previous this
Is limited to 1 to 247.
8000 Series /CS300 Hybrid digital input Single slot hot repair
The CS300 digital input module has now been replaced by hot repair
