T8431 ICS TRIPLEX
制造商:ICS Triplex
產品沒有。: T8431
系統供電電壓范圍:20 ~ 32V直流
輸入數量:40通道
自定義閾值:4-off
輸入電流范圍:0-22mA
輸入電壓范圍:0 ~ 6vdc
樣本更新時間:0.5ms
分辨率:3.9uA (1/256mA)
安全精度:滿量程+/- 1%
(默認閾值，超過該閾值將引發0x70nn系列切片差異故障)
校準精度:0.03%
建議輸入通道校準檢查
時間間隔:2
電路類型:容錯，完全三倍可選線路監控
熔斷:無熔斷，如有需要可外部熔斷
內在安全外部屏障
事件順序
事件分辨率:1ms
時間戳精度:±0.5 ms
現場公共隔離
持續工作:±250V dc
最大承受:±2.5kV dc
信道間串?dāng)_:-40至-60分貝
功耗:15 – 18W
自檢間隔:2分鐘
工作溫度:-5°C至60°C(23°F至140°F)
非工作溫度:-25°C至70°C(-13°F至158°F)
溫度變化:0.5℃/min
工作濕度:10 – 95% RH無冷凝
環境規格:參考552517文檔
高度:266mm(10.5英寸)
寬度:31毫米(1.2英寸)
深度:303mm(12英寸)
重量:1.149公斤(2.5磅)
實時時鐘分辨率:100μSec
運輸重量:2kg

T8431

微架構核心平臺Santa Rosa Santa osa刷新處理核心Penryn-3M核心步進B1Q5CP) CO(Q8LG) MOSLAPA，SLAYQ)CPUIDS674(05CP)676/08LG)10676(SLAPA，SLAYO)制造工藝0.05微米數據寬度64 bit CPU核心數2線程數2浮點單元集成一級繡存大小2 x 32 KB 88組關聯指令緩存2 x 32 KB 8路組關聯回寫數據緩存二級緩存大小共享3 MB 12路組關聯高速緩存多處理單處理器擴展與技術MMX指令SSE流式SIMD擴展SSE2/流SIMD擴展SSE3 流式SIMD擴展SSE3 /補充流式SIMD擴展SSE41 /流式SIMD擴展SSE4.1EM6T /擴展內存64技術/英特爾64VT /虛擬化技術IDA /英特爾動態加速技術安全特性NX / XD /執行禁用位低功耗特性C1/自動停止、C1/MWAIT、C2、C3、C4和C6核心狀態停止授權模式睡眠模式深度睡眠模式深度睡眠模式增強型深度睡眠模式深度掉電狀態動態FSB頻率切換

T8431

T8431 ICS TRIPLEX
Manufacturer :ICS Triplex
The product does not. : T8431
System power supply voltage range :20 to 32V DC
Input quantity :40 channels
User-defined threshold :4-off
Input current range :0-22mA
Input voltage range :0 ~ 6vdc
Sample update time :0.5ms
Resolution :3.9uA (1/256mA)
Safety accuracy: full scale +/- 1%
(Default threshold, beyond which the 0x70nn series slice differential fault will be raised)
Calibration accuracy :0.03%
It is recommended to check the input channel calibration
Time interval :2
Circuit type: Fault tolerant, fully triple optional line monitoring
Fuse: No fuse, if necessary, external fuse
Internal security External barrier
Sequence of events
Event resolution :1ms
Timestamp accuracy :± 0.5ms
On-site public isolation
Continuous operation :±250V dc
Maximum tolerance :±2.5kV dc
Interchannel crosstalk :-40 to -60 dB
Power consumption: 15-18W
Self-check interval :2 minutes
Operating temperature :-5°C to 60°C(23°F to 140°F)
Non-operating temperature :-25°C to 70°C(-13°F to 158°F)
Temperature change :0.5℃/min
Operating humidity: 10-95%RH Non-condensing
Environment specifications: See document 552517
Height :266mm(10.5 in)
Width :31 mm (1.2 in)
Depth :303mm(12 in)
Weight :1.149 kg (2.5 lb)
Real-time clock resolution :100μSec
Shipping weight :2kg
Microarchitecture Core Platform Santa Rosa Santa osa Refresh Processing core Penryn-3M Core Step B1Q5CP) CO(Q8LG) MOSLAPA, SLAYQ)CPUIDS674(05CP)676/08LG)10676(SLAPA, SLAYO) Manufacturing Process 0.05 micron data width 64 bit CPU cores 2 Threads 2 Floating point unit Integrated primary Embroidery Size 2 x 32 KB 88 group associated instruction cache 2 x 32 KB 8-way group associated write back data cache Level 2 cache size shared 3 MB 12-way group association cache multiprocessing uniprocessor Extension and Technology MMX Instruction SSE Streaming SIMD extension SSE2/ Streaming SIMD extension SSE3 Streaming SIMD extension SSE3 / Supplementary streaming SIMD extension SSE41 / streaming SIMD extension SSE4.1EM6T / Extended Memory 64 technology/Intel 64VT/Virtualization Technology IDA/Intel Dynamic Acceleration Technology Security feature NX/XD / Execute Disable bit Low power feature C1/ Auto Stop, C1/MWAIT, C2, C3, C4, and C6 Core State Stop Authorized Mode Sleep Mode Deep Sleep Mode Deep Sleep mode Enhanced Deep Sleep mode Deep Power Down state Dynamic FSB frequency switching
