VMIVME-2540是由美國通用電氣公司的工業自動化生產系列開發生產的。這些模型隨后被阿巴科系統公司購買。該系列被稱為VMIC/GE Fanuc板，專為工業線路的幾種應用而設計，例如CPU管理和輸入輸出通信。

VMIVME-2540是VMIC/GE發那科板的特定模塊之一，配備了作為智能計數器控制器的功能。該設備最多可計數4千兆事件。它配備了一系列24個離散輸出通道，可以通過各種板載跳線模塊選項進行編程。這些跳線能夠在很寬的極端電壓水平下工作。

24個輸出通道設計為提供12位分辨率。它們能夠在+/- 10 V的速率下輸出和吸收高達10毫安的電流。

為了使用VMIVME-2540進行離線測試，模擬輸入被設計為與外部電路斷開連接。

VMIVME-2540模塊設計有一個VMEbus從接口，它能夠提供4、8、16或24通道的數字信號測量和信號生成能力。這些可能的測量和信號輸出功能由一組集成系統定時控制器以及一系列相關的接口邏輯應用。

VMIVME-2540

vmivme – 2540

The VMIVME-2540 was developed and produced by General Electric’s Industrial Automation production family. These models were subsequently purchased by Abaco Systems. The series is called VMIC/GE Fanuc boards and is designed for several applications in industrial lines, such as CPU management and input/output communication.

The VMIVME-2540 is one of the specific modules of the VMIC/GE Fanuc board, equipped with functions as an intelligent counter controller. The device can count up to 4 gigabit events. It is equipped with a series of 24 discrete output channels that can be programmed with various onboard jumper module options. These jumpers are capable of operating at a wide range of extreme voltage levels.

The 24 output channels are designed to provide 12-bit resolution. They are capable of output and absorption of up to 10 mA at rates of +/ -10 V.

For off-line testing with the VMIVME-2540, the analog input is designed to be disconnected from the external circuit.

The VMIVME-2540 module is designed with a VMEbus slave interface that provides 4, 8, 16 or 24-channel digital signal measurement and signal generation capabilities. These possible measurement and signal output functions are applied by a set of integrated system timing controllers and a series of associated interface logic.

VMIVME-2540
