VMIC系列產品最初是由通用電氣的自動化工業生產部門制造和開發的，后來被Abaco系統公司收購。這些設備的功能范圍包括模數或數模轉換板、中央處理單元和一組模擬或數字輸入和輸出模塊。VMIVME-7698-146模塊是作為單板計算機構建的。

該VMIVME-7698-146單元配備了一個賽揚單槽插座370處理器。它設計了一個能夠支持Windows NT和Windows 2000的操作系統，然后是Linux、VxWorks、QNX和Solaris。

VMIVME-7698-146模塊配備了一系列嵌入式應用的特殊功能。有高達512兆字節的IDE CompactFlash(可選)。有三個可編程的16位定時器，32千字節的電池支持的SRAM。該單元能夠支持遠程以太網啟動，并配備了集成的軟件可選看門狗定時器(帶復位)。

VMIVME-7698-146能夠支持VMEbus P2連接到HD/軟驅。有一個帶有VMEbus P2輸入和輸出的PMC擴展站點。支持PC機MIP擴展站點，支持VME64模式(A32/A24/D32/D16/D08/MBLT64/BLT32)。

VMEbus配備了中斷處理程序、中斷器和系統控制器。

VMIVME-7698-34

The VMIC line of products were initially manufactured and developed by General Electric’s automated industrial division of production, and were later acquired by Abaco Systems. These devices range in functions such as analog to digital or digital to analog converter boards, central processing units, and a set of analog or digital input and output modules. The VMIVME-7698-146 module is built as a single board computer.

The VMIVME-7698-146 unit is outfitted with a Celeron single slot Socket 370 processor. It’s designed with an operating system that is able to support Windows NT and Windows 2000, and then Linux, VxWorks, QNX, and Solaris.

The VMIVME-7698-146 module is outfitted with an array of special features for embedded applications. There are up to 512 megabyte IDE CompactFlash (which are optional). There are three programmable 16 bit timers, with 32 kilobytes of battery-backed SRAM. This unit is able to support the Remote Ethernet booting, and is equipped with an integrated software selectable watchdog timer (with reset)

The VMIVME-7698-146 is able to support a VMEbus P2 connection to HD/floppy drive. There is a PMC expansion site with a VMEbus P2 input and output. A PC MIP expansion site, as well as VME64 modes (A32/A24/D32/D16/D08/MBLT64/BLT32) are supported.

The VMEbus is equipped with an interrupt handler, interrupter, and system controller.

VMIVME-7698-34
