配置:
?400 MHz超低電壓賽揚處理器
?128mb SDRAM內存
?128mb CompactFlash

部件編號:VMIVME-7700-011
產品系列:7025-01-53 -4079、7025015344079、598-01-54 -3226、5998015403226

特點:
英特爾超低電壓賽揚400 MHz/650 MHz處理器
輔助IDE上高達1gb的可啟動閃存(可選)
兩個16位和兩個32位可編程定時器
32kb的非易失性SRAM
一個PMC擴展站點
支持VME64模式
GE發那科/ VMIC的VMIVME-7700是一款全功能的基于超高速賽揚處理器的SBC，采用單插槽、被動冷卻、Eurocard形式，采用英特爾815E芯片組的先進技術，前端總線速率為100 MHz。VMIVME-7700符合VMEbus Specification Rev. C.1，具有透明的pci到VMEbus橋接，允許該板在多CPU系統中充當系統控制器或外設CPU。

VMIVME-7700-110000

Settings:
?400 MHz ultra-low voltage Celeron processor
?128mb SDRAM memory
?128mb CompactFlash

Part number :VMIVME-7700-011
Product series: 7025-01-53-4079, 7025015344079, 598-01-54-3226, 5998015403226

Features:
Intel ultra low voltage Celeron 400 MHz/650 MHz processor
Up to 1gb of bootable flash memory on secondary IDE (optional)
Two 16-bit and two 32-bit programmable timers
32kb of non-volatile SRAM
A PMC extension site
Supports the VME64 mode
The GE Fanuc/VMIC VMIVME-7700 is a full-featured ultra-fast Celeron processor based SBC in single-slot, passively cooled, Eurocard form, with advanced technology from the Intel 815E chipset and a front end bus rate of 100 MHz. The VMIVME-7700 complies with VMEbus Specification Rev.C.1 and has a transparent pci to VMEbus bridge, allowing the board to act as a system controller or peripheral CPU in multi-CPU systems.

VMIVME-7700-110000
