5SHX08F4502是集成門極換向晶閘管（IGCT）。
Hitachi Energy的IGCT都是壓裝設備，以相對較大的力壓在散熱器上，散熱器也用作電源端子的電觸點，其控制功耗通常在10^-
6W。
集成門極換向晶閘管（IGCT）是20世紀90年代后期出現的新型電力電子器件，有的廠家也稱為GCT（Gate-Commutated
Thyristor）或門極換流晶閘管，是用于巨型電力電子成套裝置中的新型電力半導體器件。
IGCT是基于GTO（門極可關斷晶閘管）結構，利用集成柵極結構進行柵極硬驅動，采用緩沖層結構及陽極透明發射極技術的新型大功率半導體開關器件。它具有晶閘管的通態特性及晶體管的開關特性，由于采用了緩沖結構以及淺層發射極技術，因而使動態損耗降低了約50%。此類器件還在一個芯片上集成了具有良好動態特性的續流二極管，從而以其獨特的方式實現了晶閘管的低通態壓降、高阻斷電壓和晶體管穩定的開關特性有機結合。IGCT使變流裝置在功率、可靠性、開關速度、效率、成本、重量和體積等方面都取得了巨大進展，給電力電子成套裝置帶來了新的飛躍。

5SHX08F4502

The 5SHX08F4502 is an integrated gate commutated thyristor (IGCT).
Hitachi Energy’s IGCTs are press-mounted devices that are pressed to a radiator with a relatively large force, and the radiator is also used as an electrical contact for the power terminal, with a control power consumption typically of 10^-
6W.
Integrated Gate commutator thyristor (IGCT) is a new type of power electronic device that appeared in the late 1990s, also known as GCT (Gate-commutated) in some manufacturers
Thyristor, or gate commutated thyristor, is a new type of power semiconductor device used in large power electronics packages.
IGCT is a new type of high-power semiconductor switching device based on GTO (gate turn-off thyristor) structure, which uses integrated gate structure for hard gate drive, buffer layer structure and transparent anode emitter technology. It has the on-state characteristics of thyristor and the switching characteristics of transistor. Because of the buffer structure and shallow emitter technology, the dynamic loss is reduced by about 50%. This kind of device also integrates a continuous current diode with good dynamic characteristics on a chip, thus realizing the combination of low on-state voltage drop, high blocking voltage and stable switching characteristics of the transistor in its unique way. IGCT has made great progress in power, reliability, switching speed, efficiency, cost, weight and volume, and has brought a new leap to power electronic complete sets.

5SHX08F4502
