特征

140CPU65260共有4個通信端口。一個Modbus (RS-232/RS-485)、一個Modbus Plus (RS-485)、一個USB和一個以太網。CPU模塊需要2760 mA的總線電流。該模塊還帶有一個鑰匙開關。它的離散(位)參考容量是62千字節，寄存器(字)參考容量也是64千字節。它的電池保質期為10年，使用壽命為12 mAh。140CPU65260使用3V鋰電池。

CPU模塊包含許多內置診斷功能。通電后，它將檢查和診斷RAM、RAM地址、執行校驗和、用戶邏輯和處理器的任何問題。運行時，它將檢查除處理器之外的所有功能。

優勢

140CPU65260固件歷史悠久。發布版本是Unity Pro V2.0。隨著時間的推移，對各種固件版本進行了50多次更改，糾正了許多錯誤和問題。您應該始終將您的模塊更新到最新的固件版本。高于3.30版的固件版本必須與5.8版的Copro一起使用。

如何使用140CPU65260

140CPU65260固件版本V3.5和所有以前的版本都包含產生多個漏洞的硬編碼后門，允許黑客(甚至遠程黑客)查看固件、修改模塊的網站、修改密碼以及下載和運行自定義固件。

140CPU65260

trait

140CPU65260 A total of four communication ports. One Modbus (RS-232/RS-485), one Modbus Plus (RS-485), one USB, and one Ethernet. The CPU module requires 2760 mA of bus current. The module also has a key switch. It has a discrete (bit) reference capacity of 62 kilobytes and a register (word) reference capacity of 64 kilobytes. It has a battery life of 10 years and a service life of 12 mAh. 140CPU65260 Uses a 3V lithium battery.

The CPU module contains many built-in diagnostic functions. When powered on, it checks and diagnoses any problems with RAM, RAM addresses, execution checksums, user logic, and the processor. At runtime, it checks everything except the processor.

advantage

The 140CPU65260 firmware has a long history. The release is Unity Pro V2.0. Over 50 changes were made to various firmware versions over time, correcting many errors and issues. You should always update your modules to the latest firmware version. Firmware versions higher than version 3.30 must be used with version 5.8 of Copro.

How to use 140CPU65260

140CPU65260 firmware version V3.5 and all previous versions contain hard-coded backdoors that create multiple vulnerabilities, allowing hackers (even remote hackers) to view the firmware, modify the module’s website, change passwords, and download and run custom firmware.

140CPU65260
