型號8406-113屬于伍德沃德EGCP-3發動機發電機控制包，負荷分擔(LS)模型系列。這種基于微處理器的單元被設計為與其他LS單元一起使用或一起使用。8406-113的額定輸入電壓為18v dc ~ 32v dc，工作溫度范圍為-20℃~ +70℃。

LS型號具有鍵盤和顯示屏界面，其中包括兩個背光LCD屏幕，使用戶可以同時監控和調整相關參數。這些屏幕顯示8行狀態信息，可選擇4行配置或告警日志信息。

使用前，8406-113必須通過“首次啟動菜單”進行配置;在引擎運行時無法編輯這些項。對于標準操作，8406-113配置點可從前面板顯示。其他配置點(連同標準配置點)可以通過ServLink通信串行鏈路從Watch Window軟件訪問。

該控制單元有九個狀態菜單，便于監控和故障排除。菜單包括:“系統狀態”、“發動機狀態”、“發電機狀態”、“同步器狀態”、“KW負載狀態”、“PF/KVAR狀態”、“I/O狀態”、“順序狀態”和“ATS狀態”(請注意:LS型號無轉換開關功能)。如果該單元設置與本地系統總線綁定到市電，并且MC單元需要執行ATS功能)。

額外的規格和說明可以在EGCP-3發動機發電機控制包LS(負載共享)型號8406-113手動26194中在線找到。

8406-113

Model 8406-113 falls under the Woodward EGCP-3 Engine Generator Control Package, Load Sharing (LS) model series. This microprocessor-based unit is designed to be used along with or together with other LS units. The 8406-113 is rated with an input voltage of 18-32 V dc, and rated for an operating temperature range of –20 to +70 °C.

This LS model has a keypad and display screen interface, which includes two backlit LCD screens, enabling users to simultaneously monitor and tune related parameters. These screens display eight lines of status information, with the option of four lines of configuration or alarm log information.

Before use, the 8406-113 must be configured through the First Time Startup Menu; these items cannot be edited while the engine is running. For standard operations, the 8406-113 configuration points are available from the front panel display. Additional configuration points (along with the standard ones) may be accessed from Watch Window software through the ServLink communications serial link.

This control unit has nine status menus to allow for easy monitoring and troubleshooting. These menus are System Status, Engine Status, Generator Status, Synchronizer Status, KW Load Status, PF/KVAR Status, I/O Status, Sequence Status, and ATS Status (please note: the LS models do not have any Transfer Switch functions. If the unit is set up with the local system bus tied to the mains, and MC unit is required to perform the ATS function).

Additional specs and instructions may be found online in the EGCP-3 Engine Generator Control Package LS (Load Sharing) Model 8406-113 Manual 26194.

8406-113

8406-113
