Woodward的EGCP-2微處理器為基礎的完整的發電機控制和發動機管理包之一,型號8406-121用于自動化和保護燃?xì)饣虿裼桶l(fā)動機為基礎的發電機組。
8406-121的特點包括:
發動機控制
發電機組同步
實際(kW)負載控制
無功(kVAR)控制
自動發電機排序(多臺)
發電集保護特性
發動機防護特性
通訊-電腦介面(通訊功能的詳細資料可參閱通訊手冊26181)
8406-121的輸入電壓額定值為150-300 Vac PT輸入,9 – 32vdc,工作溫度額定值為-20至+70℃。存儲溫度等級為-40 ~ +105℃。該單元的尺寸為282 x 358 x 69毫米,其中包括一個帶鍵盤的前面板和兩個背光LCD顯示屏。
這兩個屏幕顯示操作信息、狀態信息和調優設定點。當發動機轉速高于50轉時,背光仍然亮著。發動機不運行時,背光燈不使用5分鐘后熄滅。在電源電壓下降的情況下,它也會關閉以節省電力。顯示屏旁邊是一個紅色LED,用于指示報警條件和關機條件。
安裝和遠程通信所需的組件不隨8406-121發貨,必須單獨訂購。EGCP-2發動機發電機控制包手冊26174可以在我們上面的標簽中找到。

8406-121
One of Woodward’s EGCP-2 microprocessor-based complete generator control and engine management packages, Model 8406-121 is designed to automate and protect gas or diesel engine-based generator sets.
The 8406-121 features include:
Engine control
Generator set synchronization
Actual (kW) load control
Reactive power (kVAR) control
Automatic generator sequencing (multiple)
Protection characteristics of power generation set
Engine protection characteristic
Communication – Computer interface (Details of communication functions can be found in Communication Manual 26181)
The 8406-121 has an input voltage rating of 150-300 Vac PT inputs, 9-32vdc, and an operating temperature rating of -20 to +70 ° C. The storage temperature ranges from -40 ℃ to +105℃. The unit measures 282 x 358 x 69 mm and includes a front panel with a keyboard and two backlit LCD displays.
These screens display operational information, status information, and tuning set points. When the engine RPM is above 50 RPM, the backlight is still on. When the engine is not running, the backlight is extinguished after 5 minutes of unused use. In the event of a drop in the supply voltage, it will also shut down to save power. Next to the display is a red LED that indicates alarm conditions and shutdown conditions.
The components required for installation and telecommunication are not shipped with the 8406-121 and must be ordered separately. EGCP-2 Engine Generator Control Package Manual 26174 can be found in our label above.

8406-121
