制造商:本特利內華達
產品編號:(125712-01 + 125720-01)
產品類型:4通道繼電器模塊
輸出模塊:01 = 4通道繼電器I/O模塊
代理審批選項:00 =無
特點:
全高模塊
提供四個繼電器輸出
每個輸出都可以獨立編程
包括“報警驅動邏輯”
GE / Bently Nevada 3500/32系列4通道繼電器模塊是一個全高模塊，提供四個繼電器輸出。任何數量的4通道繼電器模塊可以放置在框架接口模塊右側的任何插槽中。4通道繼電器模塊的每個輸出可以獨立編程，以執行所需的表決邏輯。
4通道繼電器模塊上使用的每個繼電器都包括“報警驅動邏輯”。警報驅動邏輯使用AND和OR邏輯進行編程，并可利用來自機架中任何監控通道或任何監控通道組合的警報輸入(警報和危險)。這種報警驅動邏輯編程使用3500框架配置軟件來滿足應用的特定需求。
125720-01
Manufacturer: Bentley, Nevada
Product Number :(125712-01 + 125720-01)
Product Type :4 channel relay module
Output module :01 = 4-channel relay I/O module
Agent approval option :00 = None
Features:
Full height module
Four relay outputs are available
Each output can be programmed independently
Includes “Alarm driver logic”
The GE/Bently Nevada 3500/32 Series 4-channel relay module is a full-height module that provides four relay outputs. Any number of 4-channel relay modules can be placed in any slot on the right side of the frame interface module. Each output of the 4-channel relay module can be programmed independently to perform the required voting logic.
Each relay used on the 4-channel relay module includes “alarm drive logic”. The alarm driver logic is programmed with AND and OR logic and can take advantage of alarm inputs (alarms and hazards) from any monitor channel in the rack or any combination of monitor channels. This alarm driven logic programming uses 3500 framework configuration software to meet the specific needs of the application.
125720-01
125720-01
