125840-02 3500/15 Bentley 電源模塊 半高度模塊

通用交流電壓
描述-此選項使用通用交流電源和通用交流電源輸入模塊(PIM)。
輸入電壓- 110至220 Vac標稱值
85至264伏交流有效值
120至373伏交流電壓
通用交流電源和電源輸入模塊與傳統的高壓交流或低壓交流裝置不兼容。
125840-02是Bently Nevada公司開發的帶有RS232/RS422接口的RIM I/O模塊。它是本特利內華達3500系列的一部分?？蚣芙涌谀K是3500框架(RIM)的主要接口。它支持用于設置機架和獲取機器數據的專用協議。

125840-02功能描述
第一個機架插槽必須包含RIM(靠近電源)。RIM與TDXnet、TDIX和DDIX Bently Nevada外部通信處理器兼容。
盡管RIM執行一些由整個機架共享的任務，但它不是監控系統的重要組件，對整個系統的正常運行幾乎沒有影響。每個機架需要一個輪緣。對于使用三模冗余(TMR)的應用，3500系統需要TMR版本的RIM。
TMR RIM除了執行所有其他正常RIM操作外，還執行“監控通道比較”。
配置鍵鎖
用于在“運行”和“程序”模式之間切換3500框架。運行模式阻止配置修改，同時允許機架正常運行。程序模式支持本地和遠程機架配置以及標準機架操作。
通過從任一位置的支架上取下鑰匙，可以將開關留在運行或程序位置。為防止未經授權的機架重新配置，請將交換機鎖定在運行位置。通過將開關鎖定在程序位置，可以隨時遠程配置試管架。

美國本特利BENTLY3500/15電源模塊是半高度模塊，必須安裝在框架左邊特殊設計的槽口內。3500 框架可裝有一個或兩個電源(交流或直流的任意組合)。其中任何一個電源都可給整個框架供電。如果安裝兩個電源，第二個電源可做為前一個電源的備份。當安裝兩個電源時，上邊的電源作為主電源，下邊的電源作為備用電源，只要裝有一個電源，拆除或安裝第二個電源模塊將不影響框架的運行。3500 電源能接受大范圍的輸入電壓，并可把該輸入電壓轉換成其它3500 模塊能接受的電壓。對于3500 機械保護系統，有以下三種電源：
1.交流電源
2.高壓直流電源
3.低壓直流電源

滿框架電流值:
175 到 254Vac 輸入: 2.3 A rms (大)。
85 到 132 Vac 輸入: 4.5 A rms (大)。
88 到 140 Vdc 輸入: 2.5 A (大)。
20 到 30 Vdc 輸入: 10.0 A (大)。
3、輸出：前面板發光二極管
電源OK LED: 當電源工作正常時，燈亮。
單點接地線連接：為避免接地回路，系統必須提供一單點接地，電源輸入模塊為你提供了一個開關，來區別控制系統在哪兒接地。如果裝了兩個電源，那么兩個開關需要調到同一位置。電源輸入模塊出廠時，開關調到關（CLOSED）；接地系統通過末端（END）引到端子連接器上，如果系統在另一個地方接地，比如用外部安保器，需把開關調到（OPENED）。

125840-02

125840-02 3500/15 Bentley Power module Half-height module

Universal AC voltage
Description – This option uses a universal AC power supply and a Universal AC Power Input Module (PIM).
Input voltage – 110 to 220 Vac nominal value
85 to 264 volts AC RMS
120 to 373 volts AC
General purpose AC power supplies and power input modules are not compatible with traditional high voltage AC or low voltage AC devices.
The 125840-02 is a RIM I/O module developed by Bently Nevada with an RS232/RS422 interface. It is part of the Bentley Nevada 3500 series. The Framework interface module is the main interface of the 3500 Framework (RIM). It supports specialized protocols for setting up racks and getting machine data.

125840-02 Function Description
The first rack slot must contain the RIM(near the power supply). RIM is compatible with TDXnet, TDIX, and DDIX Bently Nevada external communications processors.
Although RIM performs some tasks shared by the entire rack, it is not an important component of the monitoring system and has little impact on the proper operation of the overall system. Each frame needs one rim. For applications that use three-mode redundancy (TMR), the 3500 system requires the TMR version of RIM.
TMR RIM performs a “Monitor channel comparison” in addition to all other normal RIM operations.
Configuration key lock
3500 framework for switching between “Run” and “program” modes. Run mode prevents configuration changes while allowing the rack to run properly. Program mode supports local and remote rack configurations as well as standard rack operation.
The switch can be left in the run or program position by removing the key from the stand in either location. To prevent unauthorized rack reconfiguration, lock the switch in a running position. Test tube racks can be configured remotely at any time by locking the switch in the program position.

The American Bentley 3500/15 power module is a half-height module that must be installed in a specially designed notch on the left side of the frame. The 3500 frame can be equipped with one or two power supplies (any combination of AC or DC). Any one of these power supplies can power the entire frame. If two power supplies are installed, the second power supply can be used as a backup of the previous power supply. When two power supplies are installed, the upper power supply is used as the main power supply, and the lower power supply is used as the backup power supply. As long as one power supply is installed, removing or installing the second power module will not affect the operation of the frame. The 3500 power supply can accept a wide range of input voltages, and can convert the input voltage to other 3500 modules can accept the voltage. For the 3500 mechanical protection system, there are three power supplies:
1. Ac power supply
2. High voltage DC power supply
3. Low voltage DC power supply

Full frame current value:
175 to 254Vac input: 2.3 A rms (large).
85 to 132 Vac inputs: 4.5 A rms (large).
88 to 140 Vdc Input: 2.5A (large).
20 to 30 Vdc input: 10.0A (large).
3, output: front panel LED
Power OK LED: When the power supply is working normally, the light is on.
Single point grounding wire connection: To avoid grounding loops, the system must provide a single point of grounding, and the power input module provides you with a switch to distinguish where the control system is grounded. If two power supplies are installed, then both switches need to be adjusted to the same position. When the power input module is delivered, the switch is turned off. The grounding system is led to the terminal connector through the END, if the system is grounded in another place, such as with an external security device, the switch needs to be turned to (OPENED).
