美國本特利BENTLY3500/15電源模塊可預裝3種類型電源，分別是：交流電源/高壓直流電源/低壓直流電源
常用型號：
3500/15-05-05-00 （前面板106M1079-01，后背板106M1081-01）
3500/15-02-02-00（ 前面板127610-01，后背板125840-01）

美國本特利BENTLY3500/15電源模塊是半高度模塊，必須安裝在框架左邊特殊設計的槽口內。3500 框架可裝有一個或兩個電源(交流或直流的任意組合)。其中任何一個電源都可給整個框架供電。如果安裝兩個電源，第二個電源可做為前一個電源的備份。當安裝兩個電源時，上邊的電源作為主電源，下邊的電源作為備用電源，只要裝有一個電源，拆除或安裝第二個電源模塊將不影響框架的運行。3500 電源能接受大范圍的輸入電壓，并可把該輸入電壓轉換成其它3500 模塊能接受的電壓。對于3500 機械保護系統，有以下三種電源：
1.交流電源
2.高壓直流電源
3.低壓直流電源

127610-01

The Bentley 3500/15 power module can be pre-installed with three types of power supplies, namely: AC power supply, high voltage DC power supply and low voltage DC power supply
Common model:
3500/15-05-05-00 (Front panel 106M1079-01, rear panel 106M1081-01)
3500/15-02-02-00 (Front panel 127610-01, rear panel 125840-01)

The American Bentley 3500/15 power module is a half-height module that must be installed in a specially designed notch on the left side of the frame. The 3500 frame can be equipped with one or two power supplies (any combination of AC or DC). Any one of these power supplies can power the entire frame. If two power supplies are installed, the second power supply can be used as a backup of the previous power supply. When two power supplies are installed, the upper power supply is used as the main power supply, and the lower power supply is used as the backup power supply. As long as one power supply is installed, removing or installing the second power module will not affect the operation of the frame. The 3500 power supply can accept a wide range of input voltages, and can convert the input voltage to other 3500 modules can accept the voltage. For the 3500 mechanical protection system, there are three power supplies:
1. Ac power supply
2. High voltage DC power supply
3. Low voltage DC power supply

127610-01

127610-01
