品牌 bently
型號 3500/92
品名 通訊網關監測
bently3500/92/90通訊網關監測具有廣泛的通訊能力，可通過以太網TCP/IP 和串行(RS232/RS422/RS485)通訊協議將所有框架的監測數據和狀態與過程控制和其它自動化系統集成。它也支持與3500 框架組態軟件和數據采集軟件的以太網通訊。支持的協議包括：
1、Modicon Modbus?(通過串行通訊)
2、 Modbus/TCP(用于TCP/IP 以太網通訊的串行Modbus 的另一種形式)
3、有的本特利內華達協議(與3500 框架組態和數據采集軟件包通訊)
3500/92 通過RJ45 與10BASE-T 星型拓?fù)湟蕴W(wǎng)絡連接。
3500/92 具有與3500/90 相同的通訊接口、通訊協議以及其它特點，不同的是，3500/92 具有可
組態的Modbus 寄存器功能，能提供與初始值寄存器一樣的功能。
前面板發光二極管（LED）狀態
OK LED: 指示3500/92 運行正常。
TX/RX LED: 指示3500/92 與3500 框架中的其它模塊通訊。

本特利bently3500/92/90通訊網關監測系列產品之外，3500/33 16通道繼電器模塊，3500/46M水電監測器、3500/60和3500/61溫度監測器、3500/62過程變量監測器、3500/72M活塞桿位置監測器、3500/77汽缸壓力監測器、3500/93 LCD顯示裝置和3500/95系統集成pc顯示裝置等產品，相對來說，不是經常用，有需要的客戶可以詳情咨詢~~
bently3500系列支撐運作的就是3500系統軟件在3500 機械保護系統中共有如下三個軟件包：
1. 框架組態軟件 – 用于組態所有的3500 模塊。
2. 數據采集/DDE （動態數據交換）服務器軟件：用于采集和保存來自3500 系統的靜態數據。DDE 服務器具有數據輸出功能，用于與第三方軟件集成，如工廠歷史數據、過程控制系統以及人機接口等。
3. 操作者顯示軟件 – 用于顯示3500 數據采集軟件采集的信息。

133323-01

Brand bently
Model 3500/92
Product name communication gateway monitoring
bently3500/92/90 Communication Gateway Monitoring has a wide range of communication capabilities to integrate all framework monitoring data and status with process control and other automation systems via Ethernet TCP/IP and serial (RS232/RS422/RS485) communication protocols. It also supports Ethernet communication with the 3500 framework configuration software and data acquisition software. Supported protocols include:
1. Modicon Modbus? (via serial communication)
2, Modbus/TCP(another form of serial Modbus for TCP/IP Ethernet communication)
3, some Bentley Nevada protocol (with 3500 framework configuration and data acquisition package communication)
The 3500/92 is connected to the 10BASE-T star topology Ethernet network by RJ45.
The 3500/92 has the same communication interface, communication protocol, and other features as the 3500/90, except that the 3500/92 has the ability to
The Modbus register function of the configuration can provide the same function as the initial value register.
Front panel light emitting Diode (LED) status
OK LED: indicates that 3500/92 is operating properly.
TX/RX LED: Indicates that the 3500/92 communicates with other modules in the 3500 frame.

Bentley Bentley 3500/92/90 communication gateway monitoring series products, 3500/33 16-channel relay module, 3500/46M hydropower monitor, 3500/60 and 3500/61 temperature monitor, 3500/62 process variable monitor, 3500/72M piston rod position monitor, 3500/77 cylinder pressure monitor, 3500/93 LCD display device and 3500/95 System integrated pc display device, etc. Relatively speaking, it is not often used, and customers in need can consult for details ~~
The bently3500 series supports the operation of the 3500 System software. The following three software packages are available in the 3500 Mechanical Protection system:
1. Framework configuration software – used to configure all 3500 modules.
2. Data Acquisition /DDE (Dynamic Data Exchange) server software: used to collect and save static data from the 3500 system. DDE servers have data output capabilities for integration with third-party software, such as plant history data, process control systems, and human-machine interfaces.
3. Operator Display software – used to display information collected by 3500 data acquisition software.

133323-01

133323-01
