概述特點:
以太網TCP/P功能
串行(RS232/RS422/RS485)通信能力
RJ45以太網連接
可配置的Modbus寄存器實用程序
通信網關模塊提供了廣泛的所有ACK監控值和狀態的通信功能，可與過程控制和其他使用以太網TCP/IP和串行(RS232/RS422/RS485)通信功能的自動化系統集成。它還允許與3500機架配置軟件和數據采集軟件進行以大網通信。到3500/92的以太網連接是用10BASET星型配置以大網的RJ45連接。3500/92支持原始3500/90的通信接口、通信協議和其他功能，但主要值Modbus寄存器除外。3500/92現在有個可配置的Modbus寄存器實用程序，它可以提供最初由主值Modbus寄存器處理的相同功能。
136188-02
Overview Features:
Ethernet TCP/P function
Serial (RS232/RS422/RS485) communication capability
RJ45 Ethernet connection
Configurable Modbus register utility
The Communication Gateway module provides a wide range of all ACK monitoring values and status communication capabilities that can be integrated with process control and other automation systems that use Ethernet TCP/IP and serial (RS232/RS422/RS485) communication capabilities. It also allows large network communication with 3500 rack configuration software and data acquisition software. The Ethernet connection to 3500/92 is a large network RJ45 connection with a 10BASET star configuration. The 3500/92 supports the communication interface, communication protocol, and other features of the original 3500/90, with the exception of the main value Modbus register. 3500/92 now has a configurable Modbus register utility that provides the same functionality originally handled by the primary value Modbus register.
136188-02
