138607-01 電源模塊的特點一般來說，這類模塊稱為負載POL) 電源供應系統或使用點電源供應系統 PUPS)。由于模塊式結構的優點多，因此模塊電源廣泛用于交換設備、接入設備、移動通訊、微波通訊以及光傳輸?shù)龋K電源具有隔離作用，抗千擾能力強，自帶保護功能，便于集成。
功能描述：
1.警報數據收集
報警前后的數據。
事件發生前10分鐘和事件發生后1分鐘收集1秒鐘的靜態數據事件發生前20秒和事件發生后10秒收集100毫秒的靜態值.報警前每隔10秒收集2.5分鐘的波形數據，報警后每隔10秒收集1分鐘的波形數據
2.配置鍵鎖
在任何位置都可以從機架上取下鑰匙，使交換機保持運行或編程狀態。將交換機鎖定在運行位置可防止未經授權的機架重新配置。當開關鎖定在程序位置時，可以隨時遠程重新配置機架
3.前面板發光二極管
正常LED:指示3500/22M何時正常運行TX/RX LED:指示3500/22M何時與機架中的其他模塊通信
TM LED:指示3500架何時外于行程倍增模式配置正常LED:表示3500框架具有有效的配置

138607-01

138607-01 Characteristics of the power module In general, this type of module is called the load POL power supply system or the point of use power supply system PUPS). Due to the advantages of the modular structure, the module power supply is widely used in switching equipment, access equipment, mobile communication, microwave communication and optical transmission, etc. The module power supply has an isolation effect, strong anti-interference ability, built-in protection function, easy to integrate.
Function description:
1. Alarm data collection
Before and after the alarm.
Collect static data for 1 second 10 minutes before the event and 1 minute after the event Collect static data for 100 milliseconds 20 seconds before the event and 10 seconds after the event. 2.5 minutes of waveform data is collected every 10 seconds before the alarm, and 1 minute of waveform data is collected every 10 seconds after the alarm
2. Configure the keylock
The key can be removed from the rack in any position to keep the switch running or programmed. Locking the switch in a running position prevents unauthorized rack reconfiguration. When the switch is locked in the program position, the rack can be remotely reconfigured at any time
3. Front panel LED
Normal LED: Indicates when the 3500/22M is operating properly TX/RX LED: indicates when the 3500/22M is communicating with other modules in the rack
TM LED: Indicates when the 3500 is properly configured outside the travel doubling mode LED: indicates that the 3500 frame has a valid configuration

138607-01
