3500/25系列增型Keyphasor模塊是半高雙通道模塊，用于向3500架中的監視器模塊提供Keyphasor信號。該模塊接收來自接近探頭或磁性拾音器的輸入信號，并將該信號轉換為數字鍵相器信號，該信號指示軸上的鍵相器標記何時與鍵相器傳感器重合。3500機械保護系統在正常配置中最多可接受四個Keyphasor信號，在配對配置中最多可接受八個Keyphasor信號.
3500/25 改進的鍵相器模塊是一個半高度，2 通道模塊，用來為3500 架中的監視器模塊提供鍵相位信號。此模塊接收來自電渦流傳感器或電磁式傳感器的輸入信號，并轉換此信號為數字鍵相位信號，該數字信號可指示何時轉軸上的鍵相位標記通過鍵相位探頭。每個鍵相模塊有2個輸入通道，3500 機械保護系統可安裝2個鍵相器模塊，接收4個鍵相位信號.

350025-

The 3500/25 Series incremental Keyphasor module is a half-height dual-channel module designed to provide Keyphasor signals to monitor modules in 3500 frames. The module receives an input signal from the proximity probe or magnetic pickup and converts this signal into a digital key phaser signal that indicates when the key phaser mark on the shaft coincides with the key phaser sensor. The 3500 mechanical protection system accepts up to four Keyphasor signals in a normal configuration and up to eight Keyphasor signals in a paired configuration.
The 3500/25 improved key phase module is a half-height, 2-channel module that provides key phase signals to monitor modules in 3500 frames. This module receives an input signal from an eddy current sensor or an electromagnetic sensor and converts this signal into a digital key phase signal that indicates when the key phase mark on the rotating shaft passes through the key phase probe. Each key phase module has 2 input channels, and the 3500 mechanical protection system can install 2 key phase modules to receive 4 key phase signals.

350025-
