3500/45脹差監測器是一個四通道監測器，它從渦流傳感器接收輸入信號，并用該信號驅動報警。利用3500框架組態軟件為3500/45編程，可以執行以下任何一種功能:脹差、補償式輸入脹差、機殼膨脹（CH3、CH4）。3500/45監測器使用位移輸入/輸出模塊，該模塊能接收來自以下本特利傳感器的輸入信號。
渦流傳感器：25、35和50mm擴展范圍傳感器及LVDT。
3500/45監測器的基本作用是提供1)機械保護，通過連續不斷地比較當時的轉子位移與報警設置點來驅動報警2)將重要的轉子位移信息給操作人員和維修人員。報警設置點可用3500框架組態軟件來設置?？蔀槊總€(gè)有效成比例值設置報警設置點，也可根據監測器類型為每一個或兩個有效成比例值設置危險設置點。

3500/45

The 3500/45 expansion monitor is a four-channel monitor that receives an input signal from the eddy current sensor and uses that signal to drive the alarm. Programmed for 3500/45 with the 3500 framework configuration software, any of the following functions can be performed: differential expansion, compensated input differential expansion, housing expansion (CH3, CH4). The 3500/45 monitor uses a displacement input/output module that receives input signals from the following Bentley sensors.
Eddy current sensors: 25, 35 and 50mm extended range sensors and LVDTS.
The basic role of the 3500/45 monitor is to provide 1) mechanical protection by continuously comparing the current rotor displacement with the alarm setting point to drive the alarm and 2) to convey important rotor displacement information to the operator and service personnel. The alarm setting point can be set by 3500 frame configuration software. An alarm setting point can be set for each valid proportional value, or a danger setting point can be set for each or both valid proportional values, depending on the monitor type.

3500/45
