產品描述
805405-1R裝置是由Reliance Electric制造的SF3000面板安裝單相現場電源模塊。805405-1R現場電源模塊旨在為AutoMax系列中的DC電機提共電壓可調、電流調節的勵磁過程。為此，805405-1R現場電源模塊與三相電樞電源模塊起使用，兩者都連接到同一個PMI機架?，F(xiàn)場電源模塊的SCR電橋設計為使用AutoMax編程執行軟件進行操作作。
805405-1R現場電源模塊的額定輸出電流為15安培，交流輸入電壓范圍為120至460 VAC，采用不可逆橋式，除此之外，805405-1R現場電源模塊有個電氣隔離的電源箱，它有自己的dv/dt保護和內部交流線路保險絲。還有一個自點火籍位電路，于防止電流中到起的感應電樂沖擊。805405-1現場電源模塊的整流器中總共四個SCR組成，所有SCR均配置用于全波電橋隔離變壓器是該模塊的可選組件。

805405-1R-

Product description
The 805405-1R unit is a SF3000 panel mounted single phase field power module manufactured by Reliance Electric. The 805405-1R Field power module is designed to provide a common voltage adjustable, current regulated excitation process for DC motors in the AutoMax family. For this purpose, the 805405-1R field power module is used with the three-phase armature power module, both of which are connected to the same PMI rack. The SCR bridge of the field power module is designed to be operated using AutoMax programming executive software.
The 805405-1R field power module has a rated output current of 15 amps, AC input voltage range of 120 to 460 VAC, with an irreversible bridge, in addition to the 805405-1R field power module has an electrically isolated power box with its own dv/dt protection and internal AC line fuse. There is also a self-igniting cadastre circuit to prevent the induction of percussion in the current. The 805405-1 field power module consists of a total of four SCRS in the rectifier, all of which are configured for full wave bridge isolation transformers are an optional component of the module.

805405-1R-
