AAP3798102-00130控制模塊
AAP3798102-00130通用顯示壓縮機控制模塊便用通用接線板或接線板將接線板安裝在控制外殼內，并將屏蔽電纜從接線板連接到模塊接線板端子上的每個輸入電路。Y將每根電纜的屏蔽連接到接線板旁邊的金面板。不要在模塊端連接屏蔽(在電纜模塊端切斷屏蔽并用熱縮管絕緣)。Y用屏蔽電纜將現場設備連接到端子板，AAP3798102-00130僅在設備端接地屏蔽(在電纜的端子板端切斷屏蔽并用熱縮管絕緣)。此外,應盡可能縮短端子板和設備端的外露(屏蔽外部引線的長度、直接方法Y將新電纜從現場設備傳感器，電位計)直接連接到模塊。Y將導本連接到模塊端子板上的話用釘上。將現場設備端的屏蔽接地，使最小數量的導體暴愿在噪聲環境中。

AAP3798102-00130

AAP3798102-00130 Control module
Aap37998102-00130 The universal display compressor control module then mounts the patch board inside the control housing with a common patch board or patch board and connects the shielded cable from the patch board to each input circuit on the module patch board terminals. Y Connect the shield of each cable to the gold panel next to the patch panel. Do not connect the shield at the module end (cut the shield at the cable module end and insulate it with a heat shrink tube). Y Connect the field device to the terminal board with a shielded cable, AAP37998102-00130 grounding the shield only at the device end (cut off the shield at the terminal board end of the cable and insulate it with a heat shrink tube). In addition, the exposure of the terminal board and device end should be reduced as much as possible (shielding the length of the external lead, direct method Y to connect the new cable from the field device sensor, potentiometer) directly to the module. Y Fasten the guide to the module terminal board. Ground the shielding of the field device so that a minimum number of conductors are exposed to noise.

AAP3798102-00130
