AI810 模擬量輸入模件- 產品詳情：
AI810模擬量輸入模塊有8個通道。每個通道可以是電壓或電流輸入。電流輸入能夠處理至少 30 V dc 的變送器電源短路而不會損壞。電流限制是通過 PTC 電阻來實現的。電流輸入的輸入電阻為250歐姆，包括PTC。
電壓輸入能夠承受至少 30 V dc 的過壓或欠壓 輸入電阻為 290k 歐姆。發射器電源可連接至 L1+、L1- 和/或 L2+、L2-。
特點和優點
8 個通道，適用于 0…20 mA、4…20 mA、0…10 V 或 2…10 V dc、單端單極輸入
1組8通道與地隔離
12位分辨率
輸入分流電阻由 PTC 電阻保護至 30V
模擬輸入短路保護至 ZP 或 +24 V
輸入可承受 HART 通信。

AI810

AI810 Analog Input Module – Product Details:
The AI810 analog input module has eight channels. Each channel can be a voltage or current input. The current input is capable of handling a short circuit in the transmitter power supply of at least 30 V dc without damage. Current limitation is achieved by PTC resistance. The input resistance for current input is 250 ohms, including PTC.
The voltage input can withstand at least 30 V dc overvoltage or undervoltage input resistance of 290k ohms. Transmitter power supplies can be connected to L1+, L1-, and/or L2+, L2-.
Features and advantages
8 channels for 0… 20 mA, 4… 20 mA, 0… 10 V or 2… 10 V dc, single-ended single-pole input
One group of eight channels is isolated from the ground
12-bit resolution
The input shunt resistance is protected to 30V by PTC resistance
Analog input short-circuit protection to ZP or +24 V
Input can withstand HART communication.

AI810
