AO845模擬輸出模塊適用于單個或幾余應用，具有8 個單極性模擬輸出通道該模塊循環執行自我診斷。模塊診斷包括:
1.如果向輸出電路供電的工藝電源過低，或者輸出電流小于輸出設定值和輸出設定值>1mA (開路)，則報告外部通道錯誤 (僅在有源通道上報告)
2.如果輸出電路不能給出正確的電流值，則報告內部通道錯誤。在幾余對中，模塊總線主站將命令模塊進入錯誤狀態。
3.如果出現輸出晶體管錯誤、短路、校驗和錯誤、內部電源錯誤、狀態鏈路錯誤、看門狗或錯誤的 OSP 行為，則會報告模塊錯誤。
AO845產品介紹：8 個通道，電流為 4…20 mA、適用于單個或幾余應用程序、1 組8 個通道與地面隔離
、模擬輸入短路保護至ZP或+24 V、HART直通通信

AO845

The AO845 analog output module is suitable for single or several applications with 8 unipolar analog output channels. Module diagnostics include:
1. If the process power supply to the output circuit is too low, or the output current is less than the output setpoint and the output setpoint >1mA (open circuit), an external channel error is reported (only reported on the active channel).
2. If the output circuit does not give the correct current value, the internal channel error is reported. In a few pairs, the module bus master will command the module to enter an error state.
3. If an output transistor error, short circuit, checksum error, internal power error, status link error, watchdog, or faulty OSP behavior occurs, a module error is reported.
AO845 Product Introduction: 8 channels, the current is 4… 20 mA, suitable for single or several applications, 1 set of 8 channels isolated from the ground
Analog input short-circuit protection to ZP or + 24V, HART through communication

AO845
