PXI-4071是一款7位半的高性能、多功能3U PXI模塊，可以提供兩種常用測試儀器的測量功能，即高分辨率的數字萬用表以及數字化儀。作為數字萬用表時，它可以提供快速、準確的AC/DC電壓、AC/DC電流、2線或4線電阻、頻率/周期測量以及二極管測試。在高壓隔離數字化儀模式下，PXI-4071能夠以1.8 MS/s的采樣速率采集波形。
PXI-4071 是一款高速模擬輸入模塊，適用于需要高速數據采集的應用場景。它具有以下特點：
1. 高速采樣率：PXI-4071 支持高達 1.25 MS/s 的采樣率，可以滿足高速數據采集的需求。
2. 高精度：PXI-4071 具有 16 位的分辨率，可以提供高精度的數據采集。
3. 多通道：PXI-4071 支持多達 32 個模擬輸入通道，可以同時采集多個信號。
4. 可編程性：PXI-4071 可以通過軟件進行編程和控制，方便用戶進行數據采集和處理。
5. 兼容性：PXI-4071 兼容 NI 的 PXI 系統和 LabVIEW 軟件，可以方便地與其他 NI 設備和軟件進行集成。

PXI-4071

The PXI-4071 is a 7 and a half bit, high-performance, versatile 3U PXI module that provides the measurement capabilities of two commonly used test instruments: high-resolution digital multimeters and digitizers. When used as a digital multimeter, it provides fast and accurate AC/DC voltage, AC/DC current, 2-wire or 4-wire resistance, frequency/period measurement, and diode testing. In high voltage isolation digitizer mode, the PXI-4071 is capable of acquiring waveforms at a sampling rate of 1.8 MS/s.
The PXI-4071 is a high-speed analog input module for applications that require high-speed data acquisition. It has the following characteristics:
1. High-speed sampling rate: The PXI-4071 supports a sampling rate of up to 1.25MS /s, which can meet the needs of high-speed data acquisition.
2. High precision: PXI-4071 has a 16-bit resolution, which can provide high precision data acquisition.
3. Multi-channel: The PXI-4071 supports up to 32 analog input channels and can collect multiple signals at the same time.
4. Programmability: PXI-4071 can be programmed and controlled by software, which is convenient for users to collect and process data.
5. Compatibility: The PXI-4071 is compatible with NI’s PXI system and LabVIEW software, and can be easily integrated with other NI devices and software.

PXI-4071
